Wet concrete spraying pump/concrete sprayer machine

shotcrete machine

Item	SPB8
Production capacity	3-8m3/h
System pressure	15Mpa
Working wind pressure	0.4-0.6Mpa
Maximum aggregate diameter	15mm
Total Weight	2100kg
Dimensions	310016001700mm
main motor power	30kw
Voltage level	380v
Hopper volume	0.3m3
Concrete slump	12-18cm
Dust near the machine	≤6mg/m3
Feeding height	1.1m
Fuel tank capacity	145L
Rebound rate	≤10%

High working efficiency: adopt hydraulic pumping type, high system reliability and stable delivery capacity.

Continuously adjustable injection volume: The main oil pump uses a variable displacement plunger pump, and the injection speed can be adjusted freely (the maximum adjustment volume switching times is not greater than 16 times / min).

The amount of accelerator setting is continuously adjustable: it can be adjusted steplessly according to the shot volume.

Long life of wearing parts: The service life of the wearing parts of the host is not less than 4000m3.

Equipped with an automatic lubrication system: automatic lubrication of the main sealing parts, automatic control of grease filling amount and filling time, greatly prolonging the life of vulnerable parts.

Humanized design of the product: The remote control handle is adopted for more convenient operation.
