Digital Audio |
|---|
Converters |
Cirrus Logic, 24-bit PCM, 48kH |
Digital Signal Processing |
32-bit, Floating Pont, Double precision |
Dynamic Range
(A-weighted, unity gain) |
ADC: 113dB
DAC: 113dB
CD Input to Analog Output: 110dB
CD Input to USB Output: 113dB
USB Input to Analog Output: 113dB |
Inputs |
|---|
Microphone 1/2
(Combo XLR/1/4" [6.35mm] TRS,
Mic/Line switchable) |
Analog Gain: 25dB
Maximum Input: 110mV
Gain Trim: Off to +26dB (unity at center)
Tone Control: 2-band |
Aux Input
(RCA stereo pair) |
Maximum Input: 4Vrms
Dynamic Range (A-weighted): 114dB
Gain Trim: Off to +12dB
Tone Control: 2-band |
CD/Phono Inputs 1/2
(RCA stereo pairs, switchable) |
CD: Line
Maximum Input: 4Vrms
Gain Trim: Off to +12dB
Tone Control: 3-band, full-cut to +10dB
THD+N (20kHz BW @ 1kHz): 0.004%
Phono: RIAA
RIAA Curve:+/-0.25dB
Gain (@ 1kHz): 31.5dB
Maximum Input (@ 1kHz): 106mV
Dynamic Range (A-weighted): 102dB |
Outputs |
|---|
Main Outputs (XLR) |
Gain Trim: Off to 0dB
Maximum Output: 8Vrms
THD+N (20kHz BW @ 1kHz): 0.004% Frequency Response: Flat |
Booth Outputs (XLR) |
Gain Trim: Off to 0dB
Maximum Output: 8Vrms
THD+N (20kHz BW @ 1kHz): 0.004% Frequency Response: Flat |
Master Outputs
(RCA stereo pair) |
Maximum Output: 4Vrms
THD+N (20kHz BW @ 1kHz): 0.004%
Frequency Response: Flat |
Headphone Outputs
(1/4"/6.35mm and 1/8"/3.5mm TRS) |
Maximum Output Voltage: 4Vrms (no load)
Output Power: 50mW (50 ohms)
Dynamic Range (A-weighted): 108dB |
General |
|---|
Pads |
(16) velocity-sensitive multi-color back-lit pads (8 per deck, 8 modes each) |
Faders |
(1) MAG FOUR tension-adjustable crossfader with independent Contour and Reverse controls
(2) Standard channel faders with shared Contour and Reverse controls |
Connectors |
(2) XLR outputs (Main)
(2) XLR outputs (Booth)
(1) RCA stereo output pair (Master)
(2) XLR / 1/4" (6.35mm) TRS inputs (Mic 1–2)
(2) RCA stereo input pairs (Deck 1–2)
(1) RCA stereo input pair (Aux)
(1) 1/4" (6.35mm) TRS output (Headphones)
(1) 1/8" (3.5mm) TRS output (Headphones)
(2) USB Type-B ports
(1) IEC power cable input |
Power |
Connection: IEC
Voltage: 100–240V, 50/60Hz
Consumption: 50W |
Dimensions
(width x depth x height) |
26.5" x 13.6" x 4.9"
674 x 345 x 124.3mm |
Weight
(including platters) |
23.55 lbs.
10.68kg |
