Автоматический выпрямитель для утка текстильное оборудование правильное переплетение или поклон машина проверки
- Категория: Textile Finishing Machines >>>
- Поставщик: FINE,MECHATRONICS.CO.,LTD
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.73 $* | 0.26 $* |
| Aug-15-2025 | 0.82 $* | 0.99 $* |
| Jul-15-2025 | 0.86 $* | 0.92 $* |
| Jun-15-2025 | 0.22 $* | 0.8 $* |
| May-15-2025 | 0.90 $* | 0.9 $* |
| Apr-15-2025 | 0.77 $* | 0.93 $* |
| Mar-15-2025 | 0.86 $* | 0.65 $* |
| Feb-15-2025 | 0.46 $* | 0.20 $* |
| Jan-15-2025 | 0.71 $* | 0.65 $* |
Характеристики
Product Description
FWS-CT
+. Image processing with Vision camera
Using the latest Microprocessor computer with Microsoft Windows
Precise image capturing
+. New method of correction over the ability of traditional type.
∙ (Woven)
∙ (Thick fabrics)
∙ (Micro fabric, peach skin, buffing fabrics)
+. Increase correction for twill fabric by selection sensor
+. Capability of skew and bow control in AUTO mode
Crease prevention of Superfine and Union fabric
+. SKEW and BOW BIAS control
This function can be used when there is a misalignment of left/right stenter chain.
Crease prevention and correction of concaved fabric
+. Work on both penetration and reflection
Fast and accurate correction of thick or laminated fabric
+. AUTO WIDE NARROW
Gap of detectors are automatically controlled by fabric width and this function improves a precision by extracting the certain interval signal
+. Detector number selection
Number of Detector can be selected depends on width of fabric
+. Automatic tension control system
Maintain fabric tension with bow roller based on the current signal from guide roller Encoder
+. Bow manual function with automatic mode for anti-distortion
+. Buzzer sound when Skew roller touches Limit Switch. Return mode can be activated to move the skew roller to center position automatically
+. 3BOW and Expander system are optional
Made in Korea
+. Image processing with Vision camera
Using the latest Microprocessor computer with Microsoft Windows
Precise image capturing
+. New method of correction over the ability of traditional type.
∙ (Woven)
∙ (Thick fabrics)
∙ (Micro fabric, peach skin, buffing fabrics)
+. Increase correction for twill fabric by selection sensor
+. Capability of skew and bow control in AUTO mode
Crease prevention of Superfine and Union fabric
+. SKEW and BOW BIAS control
This function can be used when there is a misalignment of left/right stenter chain.
Crease prevention and correction of concaved fabric
+. Work on both penetration and reflection
Fast and accurate correction of thick or laminated fabric
+. AUTO WIDE NARROW
Gap of detectors are automatically controlled by fabric width and this function improves a precision by extracting the certain interval signal
+. Detector number selection
Number of Detector can be selected depends on width of fabric
+. Automatic tension control system
Maintain fabric tension with bow roller based on the current signal from guide roller Encoder
+. Bow manual function with automatic mode for anti-distortion
+. Buzzer sound when Skew roller touches Limit Switch. Return mode can be activated to move the skew roller to center position automatically
+. 3BOW and Expander system are optional
Made in Korea
Specification
item | value |
Applicable Industries | Manufacturing Plant |
Showroom Location | South korea |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | New Product 2023 |
Warranty of core components | 1 Year |
Core Components | Touch Screen |
Place of Origin | South Korea |
Voltage | 220V AC~480V AC(50Hz~60Hz) |
Power | Max 2.8KVA |
Warranty | 2 years |
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Fast shipping, Fast service response
Company Profile
Price
Roller Width | Price | Packing Size(WxLxH) |
2000mm | $34,000 | 3200x1070x1820 |
2200mm | $35,000 | 3400x1070x1820 |
2400mm | $36,000 | 3600x1070x1820 |
2600mm | $37,000 | 3800x1070x1820 |
2800mm | $40,000 | 4000x1070x1820 |
3000mm | $42,000 | 4200x1070x1820 |
3200mm | $43,000 | 4400x1070x1820 |
3400mm | $45,000 | 4600x1070x1820 |
3600mm | $46,000 | 4800x1070x1820 |
3800mm | $48,000 | 5000x1070x1820 |
Certifications
FAQ
1. who are we?
We are based in Daegu, South Korea, start from 1992,sell to all around of the world. We manufacture High quality machines
2. how can we guarantee quality?
Always a pre-production sample before mass production
Always final Inspection before shipment
3.what can you buy from us?
Automatic weft straightener, Textile guider
4. why should you buy from us not from other suppliers?
1. Made in Korea
5. what services can we provide?
Accepted Delivery Terms: By shipping
Accepted Payment Currency: Dollar
Accepted Payment Type: L/C, T/T
Language Spoken: English
We are based in Daegu, South Korea, start from 1992,sell to all around of the world. We manufacture High quality machines
2. how can we guarantee quality?
Always a pre-production sample before mass production
Always final Inspection before shipment
3.what can you buy from us?
Automatic weft straightener, Textile guider
4. why should you buy from us not from other suppliers?
1. Made in Korea
2. High quality
3. Fast shipping
4. Fast and kind service
5. what services can we provide?
Accepted Delivery Terms: By shipping
Accepted Payment Currency: Dollar
Accepted Payment Type: L/C, T/T
Language Spoken: English
