2015 Manitou Mrt

Описание и отзывы

Трекер стоимости

Характеристики

1.We are in the business of exporting used construction machine over 20 years .
2.We have largest used vehicle stock yard and that make us can meet every requirments from market.
3.We have professional teams,including Repairing department,Loading department,Driving department and Exporting department.We are ready to provide you professional service to you 24 hours.
During this 20 years , we expand our business fast based on the good reputation among our customers . Choose us and we will provide you our best sincere .

Description	Unit	Parameter value
Gross weight	kg	13500
Engine power	kW	82(CUMMINS)/74.9(DDE)
Rated load	kg	4500
Maximum lifting height	mm	16700
Maximum forward reach	mm	12600
Effective load at maximum forward reach	kg	490
Center distance of load	mm	600
Luffing angle	°	-4~73
Fork angle	°	-90~18
Maximum traction force	kN	≥70
Gradeability	°	≥25
Maximum traveling speed	km/h	36
Turning radius	mm	≤5000
Braking distance	m	≤10 (Initial speed 32±2km/h)
Overall length	mm	6960
Overall width	mm	2500
Overall height	mm	2850
Wheelbase	mm	3900
Wheel tread	mm	2060
Fork length	mm	1200
