St22/ASTM 1008 /S09CK/040A10 Q195 проволока из углеродистой

WIRE

1.Produce

Steel rod coil-wire drawing-wire annealing-rust removing-acid wasting-boiling-drying-zinc feeding-wire coiling

• Wire Rod(low carbon steel, ISQ195, ASTM,SAE 1006/1008)
• Wire Drawing(draw 6.5mm wire to 4.mm or other diameter, two types of drawing methods)
• Annealing(wire go through the high temperature, improve T/S, preparation for the zinc coating)
• Zinc coating(electro GI wire and hot-dipped GI wire, dealed with electro polish and high temperature. More zinc coating, the better resistance of corrosion)
• Wire Coiling(Weight of coil/roll: 200kg, 100kg, 50kg, 25kg, 10kg, 2-8kg)

 Galvanized iron wire is made with mild steel, hard-drawn, and then galvanized. It is rust-resistant, and very versatile in applications. Galvanized iron wire can be supplied in the form of coil wire, spool wire or further processed into straightened cut wire or U type wire.

Annealing is the key determinant of the wire T/S

 2.Specification:

-Wire diameter: 0.3mm-4.0mm

-Yield strength: 195-235Mpa

-Tensile strength: 295-540 Mpa or 350-680 N/MM2

-Elongation rate: 18-25%

-Zinc coating: first grade(18-30g/m2),second grade(12-18g/m2),third grade(9-12g/m2)

Zinc coating determine the resistant to corrosion.

3.Material:

Wire Rod: Q195, Q235, SAE1006/1008

             Chemical Composition

4. Package

Weight of coil/roll: 200kg, 100kg, 50kg, 25kg, 10kg, 2-8kg

Packaging: Plastic film inside, Hessian or woven bag outside or as require

5. Application

Galvanized iron wire is mainly used in construction as binding wire, express way fencing as fencing wire, binding of flowers as wire ties in the garden and yard, and wire mesh making as weaving wires.
