2013 Новый монолитный блок светодиодов 3 Вт/5 Вт/6 Вт/7 Вт/10 Вт/15 Вт/и т. д. с соотношением
- Категория: LED Downlights >>>
- Поставщик: Zhejiang,Metals,&,Minerals,Imp.&,Exp.,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.51 $* | 0.42 $* |
| Aug-17-2025 | 0.72 $* | 0.17 $* |
| Jul-17-2025 | 0.51 $* | 0.62 $* |
| Jun-17-2025 | 0.19 $* | 0.25 $* |
| May-17-2025 | 0.7 $* | 0.8 $* |
| Apr-17-2025 | 0.76 $* | 0.28 $* |
| Mar-17-2025 | 0.70 $* | 0.0 $* |
| Feb-17-2025 | 0.78 $* | 0.52 $* |
| Jan-17-2025 | 0.99 $* | 0.5 $* |
Характеристики
2013 New product
Specification:
1.Power: 5W
2.Light Source: 5W COB
3. Input Voltage: AC85-265V
4. CCT: 2700 ~ 7000K
5. CRI: 75/82/92 available
6.Lumen: 370-410lm
7. Material: Aluminum Alloy
8 Size: Φ73*H40 mm (3")
9 Hole size: 60mm
10.Viewing angle:30 degree
11.Dimmable is available
12. CE, RoHs, PSE Approval
| Specification | Parameter |
| Model No. | CK-TDT5-03 |
| Input voltage | AC85-265V/50~60 HZ |
| Power | 5W |
| Power Efficiency | ≥0.80 |
| LED Q‘ty | 5W Sharp COB |
| Power Factor | 0.5 |
| Color temperature | Warm white (2700~3200K); Daylight (4500~5500K); Cool white(6000~7000K) |
| CRI | 75Ra,82Ra,92Ra available |
| Luminous Flux | >380lm |
| Light Efficiency | >75LM/W |
| Viewing Angle | 30 ° |
| Material | Aluminum die casting+reflector |
| Net Weight | 140g |
| Product size | Φ73*40mm |
| Hole size | 60mm |
| Color of housing | White, Black, Silver |
| Working environment | -20°C—55°C |
| Storage condition | -20°C—60°C |
| Lifespan | >30000 Hours |
| Warranty | 2 years |
Feature:
1. Adopting reflector and COB light source, And the luminous efficiency can increased to 70-75lm/w.
2. More than 30000 hours life time
3. 2 years warranty
4. Perfect thermal management, good lighting-mixed and low luminous decay
5. Easy installation: can directly replace traditional lamps
6. 80% energy saving than incandescent lights.
Guidelines for led downlight:
1. 2700K --Home, Restaurant, Hotel. Lobbies, Boutiques
2. 3000K--Libraries, Offices, Stores
3. 4100K--Showrooms, Bookstores
4. 5000K--Museums, Jewelry stores, Hospital
5. 5600K-6500K--Used to simulate outdoor conditions
Power available
3W,5W,7W,9W,12W,15W,etc.
