Вакуумные трубки тепловые вакуумные солнечные коллекторы изготовленные в

Описание и отзывы

Трекер стоимости

Характеристики



Product Category





Product Show







Specifications



manifold (inner)	red copper
manifold (exterior)	aluminum alloy
glass tube dimensions	58mm * 1800mm
daily efficiency	≥55%
heat preservation	72 hours
hail resistance	25mm
max pressure	7 bar
coating of vacuum tube	ALN/AIN-SS/CU
heat pipe	anti-freezing > -35 degree
certificate	Solar Keymark, EN12975



Working Principle

 Series Products



Models	L*W*H mm	Vacuum tube	Power output	Efficiency	Header mm	Condenser	Frame	container loading 20FT/40HQ sets	Gross Weight kg
SCM12-01	1975*982*135	58*1800*12pcs	770W	79.50%	Φ35/1.0	Φ14/1.0	AL alloy	146/350	41
SCM15-01	1975*1225*135	58*1800*15pcs	960W	79.50%	Φ35/1.0	Φ14/1.0	AL alloy	125/305	56
SCM20-01	1975*1571*135	58*1800*20pcs	1280W	79.50%	Φ35/1.0	Φ14/1.0	AL alloy	95/229	64
SCM30-01	1975*2326*135	58*1800*30pcs	1930W	79.50%	Φ35/1.0	Φ14/1.0	AL alloy	65/157	95



Trade Terms



Payment	30% T/T in advance, the rest paid against B/L copy 100% T/Tin advance for sample
MOQ	1 Set
Loading port	Shanghai / Ningbo
Package	Standard carton
Delivery	7-10 days after payment for sample 15-20 days after payment for container



Package & Shipping





Exhibition



Contact Us

Company Name: Zhejiang Shentai Solar Energy Co., Ltd
Address: No.199 Lianhong Road, Yuanhua Industry Zone, Haining City, Zhejiang Province, China
TEL: 0086-573-87861111 FAX: 0086-573-87862577
Website: www.suntasksolar.com
Thank you for taking time to visit our website , if you want to know more about factory and us , please contact us
