ACME Small Power Biogas Generator



Introduction

Suitable gas: Biogas

Gas consumption: 0.55~0.65m3/kW.h

230V 50 Hz

Running Power 2000w

Peak Power 2200W

General Temperature Requirement: -5°C~40°C

General altitude: 2000m (It may cause problem if the altitude level is higher than 2000 meters)

710*710*600mm/set  93kg/set

HS CODE: 85022000



Parameters:



1. Generator
Model	2.0GF
Rated Frequency(HZ)	50/60
Rated Output Voltage(V)	230
Rated Power Output(KVA)	2
Max. Power Output(KVA)	2.2
Power Factor(cosΦ)	0.8
Method of Regulate Voltage	Automatic voltage regulator or capacitance
DC Output	Can produce as your request
2.Engine
Model	170F
Type	Single cylinder, air cooled, four stroke, overhead valve, horizontal axis
Fuel Grade	Biogas, natural gas, liquefied gas, gas.
Bore×Stroke	70mm×64mm
Displacement(cc)	390cc
Compression Ratio	7.0  : 1
Type of Spark Plug	G5R
Ignition Method	Non-contact transistor
Starting Method	Electric
Cooling Method	Air cooling
Fuel Consumption(g/kw.h)(g/kw.h)	≤400
Oil Grade	15W/40SF
3.Other details
Engine Switch	√
AC Circuit Breaker	√
DC Circuit Breaker	Optional
Fuel Gauge	√
Oil Alert System	√
Circuit Breaker Without Fuse	√
Accessory AC Plug	Optional
Electric Starter	√
Battery Tray	√
Dimensions(L×W×H)	610×450×470mm
Net Weight(kg)	44
Gross Weight(kg)	47
20FT/40FT/40HQ Container capacity	240/485/500
authentication	9001







Pictures:











About us:





WUHAN ACME AGRO-TECH CO.,LTD limited company is located in the nine provinces of the beautiful

Jiangcheng, Wuhan, the company is now in a number of domestic, international famous food and agriculture colleges, scientific research institutions, the company carried out extensive and in-depth technical and business cooperation, and establish a long-term strategic cooperative partnership.



ACME focus on agricultural machinery, food machinery, bio-energy, agricultural engineering and food engineering etc. After many years’ of development, ACME already had customers from all over the world like North America,South America,Southeast Asia,Africa,Oceania,Mid East,East Asia,Central America etc.. Also we have contracted three sets of rice mill plant for UNDP agriculture project in Benin and projects for others UN agro & food engineerings
