Ceramic Raschig Ring is common regular packing that they are still used for refilling existing columns and other applications. Its surface ratio is higher than ceramic cylinders and balls by 30% and its ring shape has high mechanical stability.  Ceramic Raschig ring is common regular packing that they are still used for refilling existing columns and other applications. Its surface ratio is higher than ceramic cylinders and balls by 30% and its ring shape has high mechanical stability.



Ceramic Raschig rings is the first development of a random packing. Simple shape, it is the same height and diameter of the ring. Raschig rings large size (≥100mm) are structurally packed in the column, for small size<100mm below the Raschig rings and more filled with heaps way. Ceramic Raschig Rings with excellent acid resistant properties, the ability of reisting various inorganic acid, organic acids and organic solvents corrosion(except HF acid), high temperature in a variety of occasions, wide range of applications, can be used for chemical industry, metallurgy, gas and environmental protection industries in the drying tower, absorption tower, cooling tower, scrubber, regeneration tower.



Specification of ceramic raschig ring:



Size		D*H*δ	Specific surface	Void volume	Bulk number	Bulk density	Dry packing
( inch/ mm )		mm	m2/m3	m3/m3	n/m3	kg/m3	(-1
	Φ10	10*10*2	440	0.7	720000	700	1280
	Φ15	15*15*2	330	0.7	250000	690	960
1"	Φ25	25*25*3.5	190	0.78	50000	680	400
	Φ35	35*35*4.5	150	0.76	18500	650	320
1.5"	Φ40	40*40*5	126	0.75	13200	630	305
2"	Φ50	50*50*5.5	93	0.81	6400	600	177
3"	Φ80	80*80*9.5	90	0.68	1950	500	234
4"	Φ100	100*100*10	70	0.7	1000	700	172
6"	Φ150	150*150*15	50	0.68	295	790	142
