Double-head grinding machine for stainless steel surface polishing to clear and mirror finish





Item	Nominal power	Rotate speed(r/min)	Voltage	Size(L*W*H, mm)	W/unit	3-phase Asynchronous Polishing Electromotor
AUTO-PM017	3KW	2900r/min	380V	1100*400*390	48KG	Operation mode: S6=60% Class of Insulation of Stator Winding: B Taper of Shaft stretch taper thread of side: 16 degree
AUTO-PM017	4KW	2900r/min	380V	1100*400*390	52KG	4KW, RPM2900, Voltage 380V
PM017-D1	2.2/3KW	1420-2900 r/min	380V	1100*400*390	75KG	Double speed polishing machine, you can adjust the speed to 1420 or 2900 as your needs.Suitable for polishing biger metal parts.
PM017-D2	4/5.5KW	1440-2900 r/min	380V	1200*340*340	80kg	Double speed polishing machine, you can adjust the speed to 1440 or 2900 as your needs.Suitable for polishing smaller metal parts.





Different power and voltage, different pirces. If you have any question, please kindly contact us.



Advantage



Excellent with hand control, Fine polishing for metal parts surface as jewelry, rings, watch case, nacklace, buckle, tableware, arc knife, metal edge, aluminum polishing process .









The double-head polishing machine is (single speed) traditional polishing machine, economical and economical, easy to operate, with two stations for both of them to be polished simultaneously.



Matching cloth wheel or wind wheel, and polishing wax can make the product achieve the desired polishing effect.





Double speed and point polisher is based on the single speed machine combine two speed coil in a motor casing, the effect of the implementation used a double speed, by the speed of the rotary switch to choose the suitable for polishing, make the machine more flexible.

You can adjust the speed as your needs. Suitable for polishing biger metal parts.







These Bench Grinders are fitted with excellent quality motor made from superior quality stamping and die cast rotors, which are dynamically balanced. Construction of the machines are made sturdy and robust. This helps in minimizing vibrations and smooth running is achieved.



 The coil in the motor is made of copper wire, which increases the life of the motor.





Feature





3-phase induction Motor
Operation mode	S6=60%
Rated Voltage	220V
3KW and Below	Connection Y
4KW and Above	Triangle Connection
Nominal Power	50HZ
Working temperature	below 104 degree
Height above sea level	below 1000M
Nominal Power	1.5,2.2,3,4,5.5,7.5KW (2,3,4,5.5,7.5,10HP)
Others Nominal Voltage	220/380V,346V,420V or 60 HZ rate
Characteristic	Small volume, light, attractive appearance, firm structure, reliable performance









Application





1. For polishing and grinding from different angle on different work pieces.



2. Two work stations allow two workers polishing or two polishing processes by one worker at a time.



3. All casting parts ensure durable use.



4. Widespread use in process of polishing in different industries.



5. Using rough and soft  Soft muslin buff allows polishing on different position and from different angel.



6. Double speed motor allows exchange between 2 different power and rotate speed.



7. For grinding and polishing of flat and camber surface of plate materials and nails.



8.Working platform can be set up to 90 degree, allow 2 workers polishing on both sides.
