Product Description

WG Mechanical Gradually Pipe Bender

This equipment composed by the board and bending mode, with two sets of molds. Direct mode traction motor reducer, will die on the pressure in the round steel bar along the curved arc surface, simple operation, without heating and filler, economic benefits,compared with the industry's large-scale bending machine is similar effect, is Steel manufacturer of equipment necessary.

Specification

1.Our company produces the WG machinery advances gradually the type pipe bending machine, specially designs the manufacture for the light post enterprise, is the domestic origunation.
2.This machine is suitable for each kind of cone-shape illumination light post forehead curving, the curving spot does not
distort, the circular cone pole, the polygon pole maintains the original shape, the price is low.

Model	Curvig pipe diameter and thickness (mm)	Bending radius (mm)	The main motor power (kw)	Net weight (kg)	L×W×H External dimensions (mm)
WG90×4	90×4	R500-R700	3	2000	3700×3050×620
WG100×4	100×4	R600-R1000	3	2500	4300×3250×620
WG100×4	100×4	R1200-R1500	3	3000	4500×3460×620

No.	Model	Value			Unit	Note
1	Bending Diameter	φ90			mm
2	Bending Radius	R500,R700			mm	2 sets of round mould
3	Bending Tube Thickness	4			mm
4	Motor Power	model	Y132S-6
				power	3	KW
				Rotate speed	960	rpm
5	Size	L	3000	mm
				W	2300	mm
				H	620	mm
6	Weight	2300			kg
