Считыватель карт с USB-клавиатурой и магнитной

Описание и отзывы

Трекер стоимости

Характеристики



FEATURES:

Read magnetic stripe all three tracks of information,

Power up with diagnostics,

Interface: USB or RS232,

Bi-directional swiping,

Good reading confirmation by beep sound,

Threaded inserts for mounting

Low power consumption, power supplied by 5V or USB of terminal,

Full programmable reader,

JPOS & OPOS support,

Superior reading of high jitter, scratched, and worn MagStripe cards,

Function configurable upon request in factory, best performance / cost rate

Support variety systems: Windows7/8.1/10,Linux,android, etc.



SPECIFICATIONS:

Reference Standards: ISO 7811,12,13, AMMVA,CADMV and other format.

Swipe speed: 3 ~ 60 inches per second

Interface: USB2.0 Plug and Play

Operating Temperature: -20℃~60℃

Storage Temperature: -20℃~60℃

Relative Humidity: 90% non- condensing

Operating Life: approx. 800,000 passes

Dimensions: 95mm(L) X 34mm(W) X 30mm(H)

Weight: 85g

Color: black

Read error rate: <0.5%



PROGRAMMABLE

F750 is a fully programmable reader, Reader output format can be customized by the user with Windows-based magswipe configuration utility. For example, after reading and validating card data, the unit can be programmed to parse the data, insert control characters, and add prefix/suffix characters while maintain data integrity through vertical and longitudinal error checking.
