350 Вт 3 В 4A 60A промышленный Высокоточный импульсный источник
- Категория: Переключатель источника питания >>>
- Поставщик: Shanghai,Nature,Beyond,Electric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 19.97 $* | 19.68 $* |
| Jul-18-2025 | 15.97 $* | 15.11 $* |
| Jun-18-2025 | 19.58 $* | 19.98 $* |
| May-18-2025 | 19.66 $* | 19.23 $* |
| Apr-18-2025 | 15.32 $* | 15.60 $* |
| Mar-18-2025 | 18.30 $* | 18.74 $* |
| Feb-18-2025 | 18.75 $* | 18.94 $* |
| Jan-18-2025 | 18.27 $* | 18.29 $* |
Характеристики
Product Detail
| Model | LRS-350-3.3 | LRS-350-4.2 | LRS-350-5 | LRS-350-12 | LRS-350-15 | LRS-350-24 | LRS-350-36 | LRS-350-48 | |
| Output | DC Voltage | 3.3V | 4.2V | 5V | 12V | 15V | 24V | 36V | 48V |
| Rated Current | 12.5A | 10A | 6.5A | 4.3A | 3.3A | 14.6A | 9.7A | 7.3A | |
| Current Range | 0~60A | 0~60A | 0~60A | 0~29A | 0~23.2A | 0~14.6A | 0~9.7A | 0~7.3A | |
| Rated Power | 350W | ||||||||
| Input | Voltage Range | 85~264VAC, 120~370VDC; 115/230VAC by switch | |||||||
| Efficiency | 79.5% | 81.5% | 83.5% | 85% | 86% | 88% | 88.5% | 89% | |
| Inrush Current | Cold Start, 60A at 230VAC | ||||||||
| Protection | Over load | 110%-140% rated output power | |||||||
| Protection type: Constant current liimiting, recovers automattically after fault condition is removed | |||||||||
| Over Voltage | 115%-145% rated output voltage | ||||||||
| Protection type: Shut down o/p voltage, re-power on to recover | |||||||||
| Over temperature | Shut down o/p voltage, recovers automatically after temperature goes down | ||||||||
| Environment | Working Temp & Humidity | ·-30-70°C 20-90% RH non-condensing | |||||||
| Storage Temp & Humidity | ·-40-85°C 10-90%RH | ||||||||
| Safety & EMC | Withstand Voltage | I/P-O/P: 4KVAC; I/P-FG: 2KVAC; O/P-FG: 1.25KVAC within 1 min | |||||||
| Others | Dimension | 215*115*30mm (W*H*D) | |||||||
| Packing | 0.8kg/pcs | ||||||||
