Full Automatic Plate Htst Sterilizer For Flavored Milk



Description of plate type pasteurizer



Automatic plate sterilizer machine is sterilization equipment specially designed for juice,tea drinks or similar liquid materials. It is the ideal equipment that material can extend the shelf life purpose through sterilizing and cooling. According to users’ different requirements to material heating, sterilization, heat preservation and cooling, to design various technical requirements for different flow assembly, meet the technological requirements and have all kinds of security protection measures and high temperature alarm, low temperature function of the backflow. At the same time, according to users’ requirements, corresponding configuration of high accuracy of the automatic control system.



Parameter of beverage pasteurizer:



Model	Capacity (t/h)	Steam Consumption (kg/h)	Power (kw)	Steam Pressure (mpa)	Dimension (L*W*H) (mm)	Weight (kg)
HEBRO.1-NN-1	1	40	3.5	0.5	1800*1400*1800	840
HEBRO.25-NN-2	2	80	4.1	0.5	1800*1600*2000	910
-HEBRO.25-NN-3	3	120	4.1	0.5	1800*1600*2000	980
HEBRO.25-NN-4	4	160	4.1	0.5	2000*1600*2000	1050
HEBRO.25-NN-5	5	200	4.1	0.5	2300*1600*2000	1130
Process procedures: 5°C~65°C--90°C~137°C( 4s/15s/30s)--25°C Medium: ice water 2:1(2°C)    cooling water 2:1(25°C)
