Характеристики
Industrial temperature aging car headlight hot air drying oven
Our advantages
1) Direct factory with 10+ years manufacturing experience in test equipment.
2) Products are in accordance with ASTM, IEC, ISO, JIS and other international standard.
3) Overseas technical and onsite installation support, have been 8 countries, such as America, Turkey, Australia etc.
4) Professional R&D staff with more than 5 years experience in this filed.
Check more details,please click here>>>
Product Description
Industrial hot air drying oven is to make use of the electric as heat source, through heating the air by heat exchange and adopting the axial fan as the driving power, the moisture content of hot air materials is reducing so as to realize the purpose of drying. It is wildly used in pharmaceutics, food make, light and heavy, manufacture industries for the purpose of drying the material and products.
Industrial oven specifications
| Model | YPO-072 | YPO-270 | YPO-480 | YPO-600 | YPO-720 | ||
| Inner chamber size W×H×D(cm) | 40×45×40 | 60×90×50 | 80×100×60 | 100×100×60 | 120×100×60 | ||
| Exterior chamber size W×H×D(cm) | 90×105×55 | 110×160×65 | 130×170×75 | 150×170×75 | 170×170×75 | ||
| Temperature range | Room temperature+20~300℃, or 400, 500, 600℃ | ||||||
| Perform-ance | Temp.& humi fluctuation | ±0.3℃ | |||||
| Temp.& humi uniformity | ±1%℃ | ||||||
| Temperature resolution | 0.1℃ | ||||||
| Heat up time | 30min | ||||||
| Material | Exterior chamber material | Cold-rolled steel+Powder coating | |||||
| Interior chamber material | SUS#304 Stainless steel plate(Use SUS#201 when max.temp.is below 200℃) | ||||||
| Insulation | PU&fiberglass | ||||||
| System | Wind circulation | Cooling fan | |||||
| Heating system | SUS#Stainless steel high-speed heater | ||||||
| Controller | SAMWONTECH ST590-00 controller | ||||||
| Other components | Cable port(dia.50mm),control status indicator,loading shelf(2pcs,position-adjustable) | ||||||
| Safety devices | Over-heat protection circuit breaker,overload protection,overload indicator | ||||||
| Power supply | AC 3phase380V 60/50Hz | ||||||
| Customization | Non-standard or special requirements are all welcome | ||||||
Characteristics of hot air drying oven
1. Fine powder coating treatment; Inner SUS201/304 stainless steel.
2. Use new high temperature resistant long shaft motor
3 Turbine fan.
4. Silicone forced tight.
5. Over-temperature protection, super load automatic power system.
6. Circulation system: air force level cycle.
7. Heating system:PID+S.S.R.
8.The thermostat: PID microcomputer control, automatic constant temperature, temperature quickly compensation function
9. Timer: temperature to time, when the power failure alarm indication.
10.According to customer demand matching glass window can be customized according to customer specifications specified.
Custom service of oven, your exclusive customization
| Desktop type of oven | Mutiple independent layers | Your exclusive color |
 |  |  |
