1) Flexitank which is one economical Packing solutions for liquid products.

2) Flexitank to suit 20' containers.

3) The flexitank can load more than 15% higher IBCs for20 ft. Container

4) The flexitank can load more than 44% higher than drums for20 ft.

5) Low weight of Flexitank - so higher payloads possible

6) Capacity ranges from 14,000 to 24,000 liters, suits for 20ft container

The Type Of Our Flexitank:

1) Top Loading &Discharging.

2) Bottom Loading &Discharging.

3) Top loading &Bottom Discharging.

Special Design Of Our Flexitank:

1) Anti-suction Valve.

2) PE Bonnet (our self-owned design)

Avoids contamination from any spill out of the flexitank while loading or unloading the liquids

Protects the Valve.

Main Composition:

Inner layers PE( food grade 4 layers*0.125mm/2 layers*0.35mm)+ 1 outer layer PP(220g/with high tensile strength, wearable) +2''/3''/4''valve+ valve gasket+ Bonnet .

Accessories:

1) Steel Bar (2400* 50mm)—5pcs t.

2) Corrugated Paper (L: 3000mm)—1 roll t.

3) Cardboard (2400mm*1500mm)—1 pc t.

Assistant Items for Your Special Liquids:

1) Heating pad

For easy-crystallized liquids like honey, syrup, palm oil, and animal oil tec.

2) Air Release Valve.

For easy-fermented liquids to expel air in the fllexitank generated from fermentation.

Product Description

Capacity	16,000Liters to 24,000Liters
Muli ply PE+out PP bag	4x0.125mm ply= totally 4 layers PE
Loading/Discharging	Top loading/discharging / Bottom loading/discharging
Valve	1. Traditional 3" butterfly valve with anti-suction devise
	2. Revolutionary 3" ball valve
	a) Compared with butterfly valve, ball valve is sealed more tightly and with better resistance to pressure. There is no block when valve is opened, which make liquid flow through freely and quickly.
	b) In the joint position between internal valve and flexitank, a safety protection device is added. This device could effectively prevent inner film blocking the valve, and make residual liquid the minimum after discharging.
	3.valve with 2" or 2.5" quick connector for choice
Flange	Hard PP instead of steel to reduce the pressure against the flexitank surface thus reduce the risk of failures.
Safety Pin	Added on 3” valve to help to source thefting activities if happened during transportation.
Automatic Air vent	The special design of air vent could automatically release air pressure when it is more than 0.0065Mpa inside of the flexitank. It would keep the cargo and flexitank safe during loading and transportation.
Upgrading on protective out PP woven bag	Our engineers tracked and tested 1000 pieces of flexitanks at different transportation modes and conditions. We made those of the following revolutionary upgrading:
	a)Protective out layer of BLT flexitank is 8m seamless tubular construction which would eliminate longitudinal seams.
	b)Protective out layer of BLT flexitanks are made of high-tech aramid fibers, and it has incomparable advantage at tension and softness performance against ordinary PP fibers.
	c)Each 10cm between woven of the protective layer, there is a high strength zonal reinforcing rib. Their application will make an innovative upgrade in the flexitank safety area.
Packing Capacity in Containers(20" & 40")	Cargo/Container	20"	40"
	Flexitank only	100 pcs	220 pcs
	Flexitank with accessories	65 units	140 units
