Характеристики
Product Description
1:The underground mining dumper has been improved many times, with great power, heavy load .
2:Rugged and durable, with minimal road requirements.
3:The dumper is flexible and easy to operate, and is very popular among customers.
4 : Long working hours after charging is completed.
Product Parameters
Model | ZY-155 | ZY-165 | ZY-180 | ZY-190 | |||
Loading capacity | 1000kg | 1500kg | 2000kg | 3000kg | |||
Voltage | 48V | 60V | 72V | 72V | |||
Overall size | 2600*900*1200mm | 3000*1100*1200mm | 3300*1200*1400mm | 3600*1200*1400mm | |||
Cargo box sizes | 1500*1000*400mm | 1600*1000*500mm | 1800*1200*500mm | 2000*1200*500mm | |||
Weight | 520kg | 850kg | 1000kg | 1400kg | |||
Battery model | 185A | ||||||
Rear tire type | 450-14 | 500-14 | 600-16 | 700-16 | |||
Front tire type | 400-14 | 450-14 | 450-14 | 450-14 | |||
Work platform height | 600mm | 700mm | 720mm | 730mm | |||
Operating speed | 15-25km/h | ||||||
Charging time | 6h-8h(1st is12h) | ||||||
Working time | 10h-12h | ||||||
Lifting Motor Power | 1000w | ||||||
Driving motor Power | 1000w | 1500w | 3000w | 7000w | |||
Detailed Images
1.The driving motor we adopt with high quality, operation solid structure, high rate and large capacity.
2.The oil pump deliver high pressure fuel to the oil pipe to provide energy for the vehicle.
3.Six 72V batteries were used as the power source.Equipped with high performance traction battery, first charge 12 hours, after 6-8 hours each time.
4.The hydraulic cylinder is strong enough to keep the vehicle moving steadily.
5.The spring steel plate has strong toughness, can cushion and reduce shock.
6.The joy stick easy shift and flexible operation.
7.The hydraulic cylinder can rise to 3 sections and maximum tilt angle of 45 degrees.
8.The brake pedal is convenient operation and moderate strength.
9.The lifting motor with good speed regulation performance, uniform speed smooth speed regulation.
Packing and shipping
LCL (Less than container load)
FCL(full container load)
Service and Warranty
Pre-sale service:Introduce the company's self-loading mini dumper in detail and solve the doubts patiently.
Sale Service:Pay attention to details to ensure product quality, timely delivery, make customer satisfaction.
After-sale Service:Provide technical guidance and auxiliary maintenance, provide regular telephone or home return visits to consumers.
After-sale Service:Provide technical guidance and auxiliary maintenance, provide regular telephone or home return visits to consumers.
