D20KQ FP20000Q Sanway 4-канальный цифровой обработки сигналов мощности

DSP

MODEL:

D20KQ DSP power amplifier

Input:

4 channel

Output:

4 channel

PC Com Port:

1 USB Com Port on front   panel, 1 USB Com Port,2 RS485 Com Port on back panel (RJ-45)

Processor:

48KHz Sampling frequency,   48-bit Fixed-Point DSP, 24-bit A/D and D/A converter

Dynamic range:

>110dB

Frequency Response:

±0.25dB,  20Hz ---   20KHz

Distortion:

< 0.01%, 20Hz - 20KHz @   +10dBu balanced input

Signal to noise ratio:

>110dB

crossover filter:

Each output channel can be independently set as LPF and HPF and APF, The   parameters can be adjusted,   Filter type:Butterworth, Bessel,   Linkwitz-Riley;   The Crossover Frequency:20Hz---20KHz,     Slope:12,18,24 or 48 dB/octave

EQ:

Bandwidth:0.2 to 36 oct,    Frequency:20Hz to 20KHz, Gain: -24dB to +12dB, step:0.2 dB

Delay:

0ms to 115ms

Display:

2 x 20 LCD

Store Settings:

20 user program dynamic   storage

AMPLIFIER

 Model

            D20KQ

 Output Power

 8Ω Stereo Power

            4×2100W

 4Ω Stereo Power

            4×4000W

 8Ω Bridged Monon Power

             2×8000W

 Frequenty Response

20Hz-20kHz  ±0.5dB

 THD+N(Rated   power,4Ω/KHz)%

0.10%

 Signal Noise   Ration(dB)

110dB

 Input Impedance

20KΩ Balanced / 10kΩ   Unbalanced

 Output Connectors

Speakon Connectors(NEUTRIK)

 Power Requirement

100-120V-50-60Hz    or  200-240V-50-60Hz

 Dimension

483×377×88mm

Net weight

13kg
