220V online ups nobreak power supply for home /office appliance 6KVA/4.8KW 10KVA/8KW

        Features

• 1.Input frequency range 40 ~ 70Hz, support various fuel generators;
• 2.With LCD+LED real-time display, UPS operating available for Detection;
• 3. With self-diagnosis function, can detect hidden faults of UPS;
• 4.Cold start by battery without grid input
• 5.With input neutral line and live line detection function, avoid the reverse connection of UPS utility input;
• 6.N+1 parallel redundant design, available for 3 parallel connections, greatly improving system reliability;
• 7.Standard RS232 communication outlet, connect UPS and computer to realize multifunctional and multi-purpose monitoring and management operations, available SNMP card (optional) to UPS remote monitoring function.

• Application

  widely used in the communication industry billing center, communication base station, banking outlets, ATM and network office environments of securities, transportation, electric power, industry.

• Type		H6K	H6KS	H10K	H10KS
  Capacity	VA/W	6KVA/4.8kW		10KVA/8KW
  Input	Input wire	Single phase two wire + ground wire
  	Voltage range	120-275V
  	Frequency Range	50/60HZ Auto sensing
  	Distortion	<5%
  	Power factor	≥ 0.99
  	Generator input	support
  Output	Voltage range	220*(1+1%)VAC
  	Frequency (same Frequency mode)	46-54Hz/56-64Hz(Synchronized with the input utility frequency)
  	Frequency	50(1+1%)/60(1+1%)Hz
  	(battery mode)
  	Power factor	0.9
  	Crest ratio	3:01
  	Harmonic distortion	≤ 3%THD( Linear load )
  		≤ 6%THD( Nonlinear load)
  	Output waveform	Pure sine wave
  	output method	Terminal block
  Efficiency	Overload capability	Utility:105%-125%,1min;125%-135%,30S;>135%,0.5S
  		Battery: ≥ 105% for 30 S
  	Charging mode	90%
  	Battery mode	90%
  	Utility priority mode	97%
  Battery	Type of battery	12V/7AH	/	12V/7AH	/
  	Number of batteries	16		16
  	Equipment time	>5min		>5min
  	(full load)
  	Charging time (90%)	8Hours		8Hours
  	Rechargeable battery (maximum)	1.0A	5.0A	1.0A	5.0A
  	Rated charging voltage	218.4VDC
  	Temperature text	support
  Transfer time	Utility to battery	0ms
  	Inverter to bypass	4ms
  Other characteristics	Mains priority mode	Support
  	Normal mode	support
  	(constant voltage constant frequency)
  	Parallel redundancy	3 sets (maximum)
  Indicator light	LED display	Load Status / Battery Capacity / Battery Mode / Bypass Mode / Fault
  	LCD display	Load / Battery / Input / Output / Operating Mode
  	Battery mode	alarm every 4 seconds
  Alarm sound
  	Low electricity	alarm every second
  	overload	alarm 2 every second
  	malfunction	continuous alarm
  Shape	Dimension	248*500*616	240*500*460	248*500*616	240*500*460
  	(D*W*H) mm
  	Net weight (Kg)	57	18	67.5	20
  Use environment	Operating environment	0~40℃
  	Humidity	20~90%( Non-condensing)
  	Noise Level	<55db@1Meter
  	Micro RS-232	Support Windows 2000/2003/XP/Vista/2008/7\\Linux\\Unix & MAC
  Interface
  	USB (optional)	Windows y & MAC
  	Slot (optional)	SNMP/AS400 Relay Card/Rs485
  	EPO (optional)	Support emergency shutdown
