Kтип регулятор температуры с термопарным компенсации провод NiCr-10 подводящего
- Категория: Запчасти и аксессуары для инструментов >>>
- Поставщик: Shanghai,Shenyuan,Hi-Temp,Wire,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.28 $* | 0.99 $* |
| Aug-17-2025 | 0.91 $* | 0.85 $* |
| Jul-17-2025 | 0.71 $* | 0.83 $* |
| Jun-17-2025 | 0.11 $* | 0.9 $* |
| May-17-2025 | 0.49 $* | 0.63 $* |
| Apr-17-2025 | 0.78 $* | 0.67 $* |
| Mar-17-2025 | 0.21 $* | 0.41 $* |
| Feb-17-2025 | 0.13 $* | 0.56 $* |
| Jan-17-2025 | 0.20 $* | 0.41 $* |
Характеристики
Product Description
"Protecting high-temperature electricity safety" is our development policy, Carefully manufacturing every meter cable, protect the high temperature environment electricity safety is the mission of the company.
Description
1) KX cable
2) Style No.: KX, NX, EX, JX, SC, RC, NC
3) Size: 2*0.3~2.5mm²
4) Rated Voltage: 300/600V
5) Rated Temperature: -60°C~+1000°C
6) Conductor: Nickel-chrome, Nickel-silicone, Iron, copper-nickel, copper
7) Insulation: FEP or silicone rubber
8) Color:red / yellow / blue / white / black/ yellow green / brown / orange / purple / green / etc
Product features
within a certain temperature range (including room temperature), with the matching thermocouple thermoelectromotive force with the same nominal value of a pair of insulated wire, connect them with thermocouple and measuring device, To compensate for the errors in their temperature changes at the junction with the thermocouple. Divided into extended and compensated.
Applications
* Metallurgy
* chemical industry, petroleum
* power generation
* defense and scientific research
* cables for connection between thermocouples and temperature display instrument.
| Type | Conductor | Grade | Working temperature | Tolerance | |
| Insulation material | deg.C | ||||
| S | Cu, Ni-Cu | A | + 3oC | ||
| B | PVC | -25~70C | + 5oC | ||
| R | Cu, Ni-Cu | A | + 1.5oC | ||
| B | Silicone: | -60~200C | + 2.5oC | ||
| K | Cu, Ni-Cu/ | A | + 1.5oC | ||
| Ni-Cr, Ni-Si | B | FEP/PFA | -60~250C | + 2.5oC | |
| N | Cu, Ni-Cu/ | A | + 1.5oC | ||
| Ni-Cr, Ni-Si | B | Fiberglass | -60~500C | + 2.5oC | |
| E | Ni-Cr,Ni-Cu | A | + 1.5oC | ||
| B | Kapton | -60-300C | + 2.5oC | ||
| J | Iron,Ni-Cu | A | + 1.5oC | ||
| B | + 2.5oC | ||||
| T | Cu, Ni-Cu | A | + 0.5oC | ||
| B | + 1oC | ||||
