AC-DC преобразователь импульсная печатная плата блок питания pcba переменный ток 220-110 В в постоянный 12 ма 3 6 Вт/Вт трансформатор smt

Описание и отзывы

Трекер стоимости

Характеристики

AC-DC converter switching PCB board,power supply module pcba assembly,AC 220V-110V to DC 12V ma 3.6W/W transformer smt assembly

Printed circuit board production PCBA Details

pcba Assembly electronic PCBA SMT Assembly PCBA

Specification of PCBA assembly

PCBA Type of  Assembly	SMT,DIP, Mixed(surface mount and through hole) technology,Cable assembly
Solder Type of electronic PCBA	Water Soluble Solder Paste,Leaded and Lead-Free
Minimum IC Pitch for OEM PCBA	0.2mm
Minimum chip size PCBA board	0201 (0.2x0.1)/0603 (0.6 x 0.3mm)
Maximum BGA size SMT Assembly PCBA	74x74mm
BGA ball pitch PCBA	1.00mm (minimum),3.00mm (maximum)
BGA ball diameter Pcba Assembly	0.40mm (minimum),1.00mm (maximum)
Components	BGA and VFBGA
	Leadless Chip Carriers/CSP
	Double-sided SMT Assembly pcba
	Fine Pitch to 0.8mils
	BGA Repair and Reball
	Passive components
	As small as 0402 package
	As small as 0201 with design review
	Ball Grid Arrays(BGA)
	As small as .5mm pitch
	Part Removal and Replacement
Bare Board Size	Smallest:0.25*0.25 inches
	Largest:20*20 inches
File Formate	Bill of Materials
	Gerber files
	Pick-N-Place file
Types of  Service	Turn-key,partial turn-key or consignment
Component packaging	Cut Tape,Tube,Reels,Loose Parts
Turn Time	Same day service to 15 days service
Testing	First prototype test before mass quantity production,Flying Probe Test,X-ray Inspection AOI Test,BGA X-ray, PCB E-test



One-Stop Service:

1.High-end, Small volume and Various kinds of PCBA service offered;

2.Speedy, Flexible and one-stop service in PCBA;

3.Assembly and Purchasing service offered, all components  are promised purchased 100% from Original factories or their pointed agents;

4.Transparent quotation,cost and benefit are detailedly opened to customer;

5.With professional Engineers and Long-term successful experience in cooperating with customers inland and overseas,

all new projects can be developed faster and better than expected;

6. Technical backbone workers have more than 5 years'working experience and 85% of front-line operators have more than 3 years' working experience

7.With USA or Japan imported tin cream and tin bar, and 100% AOI testing during   production, all PCBAs we made are more reliable.

8. Workshops strictly implement 5S production standards.



SMT and Dip Equipment

Advanced SMT Equipment:

* HITACHI Screen Printer

* FUJI NXT-Ⅱ & FUJI XPF-L Modules

Assembly Production Machines:

* 2 automatic YAMAHA YS24 and YS12 SMT lines and 3 automatic MX400 and MX200 STM lines

* 2 DIP Dual wave soldering line

* 2 manual soldering production line

Capacity:

* 180 million points per month

Component range:

* 0201,0402,0603,0805,1206,1608,2125,3216

* Fine Pitch QFP to 0.2mm

* BGA, Flip Chips, Connectors

* BGA to 0.2mm

Testing Equipment

* Printing Solder Paste Test

* AOI(Automatic Optical Inspection)

* X-Ray for BGA and QFN Testing

* Function Testing

* In Circuit Testing

* Testing Service



electronic PCBA OEM PCBA Smd Pcba SMT Assembly PCBA

pcb circuit board SMT Process



Our other PCBA board main product

Our Advantage

Certification of Metal pcb circuit board

About US

Our Factory of Metal printed circuit board





Our Exhibition

Our Customer Feedback

Packaging&Shipping

Our company is not only trying to give customers a good product,

but also pay attention to offering a complete and safe package. And here we prepare some personalized services for all the orders.



Common packaging:

PCB:  Sealed bag, Anti-static bags, Suitable carton.

PCBA:  Antistatic foam bags, Anti-static bags, Suitable carton.



Regular Cartons Specification.

No. Dimension (L*W*H)

Small Size :         33cm*28.5cm*18.5cm

Medium Size:     44.5cm*30cm*15cm

Big Size:              51.5cm*32.5cm*17.5cm



Customized Cartons:

Carton outside according to the requirements

of customers printed the name of the customer address,

mark, the customer needs to specify the destination and other information.

FAQ

1.WWhat service do you have?

   We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal, final assembly,testing and other value-added service.



2. What files required to get quotation from you?

For PCB quotation, please provide the Gerber data/files and indication of related technical requirements as well as any special requirement if you have.

For PCBA quotation, please provide Gerber data/ files and also BOM (bill of materials), and if you need us to do function test, please also provide the test instruction/procedure.



3.How long does it take for PCB quote?

  Normally 24 hours to 48 hours as soon as receive internal engineer evaluate confirmation.



4. Can we inspect quality during production?

  Yes,we are open and transparent on each production process.We welcome customer inspect our production process and check in house.Or contact our customer service to view the factory panorama online.



5. How can we ensure our information should not let third party to see our design?

  We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential leve

pursuits.



6.Do you have any minimum order quantity (MOQ) requirement?

No, we do not have MOQ requirement, we can support your projects starting from prototypes to mass productions.
