Промышленная духовка для пекарни газовая порошковое

Product Features:

Mainly to provide power for the oven mesh belt, drive the network I run;

Machine configuration:

1, using carbon steel mesh belt, thickness 1.2mm, width 600mm, working height 1100mm;

2, including the main and slave seats, the diameter of the front and rear rollers is φ900mm, and the width of the roller body is 550mm;

3, the main motor power: 4KW, stepless frequency control, the conveyor speed can be adjusted;

4. The steel belt pneumatic tensioning device and the automatic adjusting device are designed to ensure the excellent running effect of the steel strip;

5, the design has automatic power failure UPS device: DC motor, power 3KW, to ensure that the steel belt can still operate normally after a sudden power failure;

6. A cleaning device such as a brush cleaning device, a scraper device, and a scraper device is provided to ensure the cleaning of the mesh belt;

7. The outer cover is made of stainless steel; the frame material is made of national standard channel steel, and the surface is painted and painted.

8. Install safety protection devices such as emergency stop switch and automatic alarm;

9. The motor and reducer use the Siemens brand;

10. Control the use of German brands: SIEMENS;

11, the bearing uses the US UBC brand, TR with bearing;

Wooden case.

1.Product production is completed, by the quality inspection department to check

2.After inspection qualified, clean for whole machine

3.Packing:

a. Inside the machine put desiccant

b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrapc. On wood packaging on the outside of the machine, then use metal reinforcement with steel

4.Container:according to different products for reinforcement

Shanghai Target Industry Co., Ltd is the sales and service company for Shanghai SHINWEI Machinery Manufacturing Co., Ltd which is the first manufacturer to build the complete production line for depositing hard candies in China and has accumulated 40 years' fabrication experience. It is also one of the leading and professional exporters in China by providing customers home and abroad with high quality confectionery, chocolate, biscuit and packaging machinery. Our machineries have been exported to East European, south America, middle east, southeast Asia.

As the first-class corporation for fabrication of confectionery, chocolate, biscuit and packaging machinery, Target Industry offers not only the advanced equipment with competitive and economical efficiency, but the whole solutions for the customer's demands also. We provide the design, production, assembly and commissioning work of small or medium confectionery and biscuit machines in accordance with the customer's specific requirements.

Why choose us?

a.Established in 1982, nearly 20-year experiences in the area of machinery manufacturing of food processing;

b.Cooperate with well-known enterprises for some mechanical parts;

c.Adopt environment-friendly and food-grade materials;

d.Offer customized machineries and give suggestion for plant layout.

After-sale services for all the customers



a. Free training of machine installation, operation and maintenance will be provided;

b. Some spare parts will be sent together with the machine for free and some spare parts are always at favorable price for regular customers;

c.Technical support will be offered by call, email or video etc;

d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance.
