Фабрика OEM 43 дюймов Изогнутые 4K ЖК-модуль дозатора могут варьироваться в зависимости от игр
- Категория: ЖК-мониторы >>>
- Поставщик: Fujian,Gamet,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 771.45 $* | 810.53 $* |
| Aug-20-2025 | 765.2 $* | 803.11 $* |
| Jul-20-2025 | 642.3 $* | 674.16 $* |
| Jun-20-2025 | 752.66 $* | 790.97 $* |
| May-20-2025 | 654.77 $* | 687.96 $* |
| Apr-20-2025 | 739.83 $* | 776.57 $* |
| Mar-20-2025 | 732.73 $* | 769.47 $* |
| Feb-20-2025 | 726.54 $* | 762.6 $* |
| Jan-20-2025 | 719.38 $* | 755.91 $* |
Характеристики
Factory OEM 43 inch curved 4K LCD Module customize for gaming and displaying
Product Description
The 43in-3T Curved Module is a Color Active Matrix Liquid Crystal Display with an integral the Source PCB and Gate implanted on Panel (GIP). The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in the normally black mode. It has a 42.51 inch diagonally measured active display area with QWUXGA resolution (2160 vertical by 3840 horizontal pixel array). Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot. Therefore, it can present a palette of more than 1.07Bilion colors.
It has been designed to apply the 10-bit 8 Lane VbyOne interface.
It is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important.
Features
| Active Screen Size | 42.51 inches(1,079.75 mm) diagonal | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Outline Dimension | 953.0(H) x 543.0 (V) x 12 mm(D) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pixel Pitch | 0.2451 mm x 0.2451 mm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pixel Format | 3840 horiz. by 2160 vert. Pixels, RGB stripe arrangement | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Display Mode | IPS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Color Depth | 10-bit(D), 1.07 Billion colors | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Drive IC Data Interface | Source D-IC : 8-bit EPI, gamma reference voltage, and control signals Gate D-IC : Gate In Panel | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Transmittance(with POL) | 4.01%(Typ.) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Viewing Angle (CR>10) | Viewing angle free ( R/L 178 (Min.), U/D 178 (Min.)) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Consumption | Logic= 10.25W (Typ.) 13.35W (Max.) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Weight | 1.5Kg (Typ.) , 1.56Kg (Max.) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Display Mode | Transmissive mode, Normally black | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Surface Treatment (Top) | Hard coating(2H), Anti-glare low reflection treatment of the front polarizer (Haze 3%(Typ.)) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Application
Company Introduction
Fujian Gamet Technology Co., Ltd has been established for 10 years in Changting, Fujian Province, which owned a 2000 m2 factory.
As a National High-Tech enterprise, Gamet is specialized in R&D, manufacturing and marketing of open frame monitors, touch screen monitors, touch panel with full range selection from 13 inch to 55 inch.
Till now, Gamet has developed many of different models which are widely applied in Entertainment & Gaming, Medical OEM, Automation & Industrial, Retail, different kinds of registration, Transportation & Touch screen Display and so on. Today, our products have been exported to more than 20 countries around theworld. Besides the standard products we supply, Gamet also offers professional services in customizing products and project management to satisfy all customers' requirements.
Gamet would like to develop together with our entire customer strongly. We are always in the pursuit of "High Quality" "Speed Service" Professional Attitude" and "Innovative Thinking" to create higher values for our customers.
FAQ
1. Q: Are you a factory or trading company?
A:We are a factory who has been specializing in producing LCD display for years.
2. Q: How does your factory do regarding quality control?
A:Quality is priority.Gamet people always attach great importance to quality controlling from the beginning to end.
3. Q: What is your after-sale service?
A: We offer 100% guarantee on our product .
4. Q: What is your MOQ?
A: Any quantity is acceptable for your order. And the price is negotiable for large quantity.
5. Q: When will you make the delivery?
A: The delivery will be within 3-20 working days according to the size and quantities of your order.
6.Q:If you are not online,how can i get contact with you?
A. We have all kinds of social sofeware to get in touch with each other, like whatsapp, skype, we chat, email and so on.We will reply customers ASAP.
We chat: 18750903601
Tel:+8618750903601
