Цена по прейскуранту завода-изготовителя sinomada мини-6T стрелы-башенный кран
- Категория: Tower Cranes >>>
- Поставщик: Sinomada,Heavy,Industry,(Changsha),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.22 $* | 0.8 $* |
| Aug-19-2025 | 0.57 $* | 0.34 $* |
| Jul-19-2025 | 0.34 $* | 0.65 $* |
| Jun-19-2025 | 0.84 $* | 0.58 $* |
| May-19-2025 | 0.60 $* | 0.53 $* |
| Apr-19-2025 | 0.66 $* | 0.36 $* |
| Mar-19-2025 | 0.33 $* | 0.12 $* |
| Feb-19-2025 | 0.1 $* | 0.76 $* |
| Jan-19-2025 | 0.34 $* | 0.24 $* |
Характеристики
New Type SINOMADA Luffing-jib Tower Crane L80-6S
Good Quality & Best price
Product Description
1.Performance parameters of L80-6S: performance parameters and technical indexes reach both domestic and international advanced level.
• Max. jib length: 10m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length is15 meters.
• Max. lifting capacity: 6t;
• Max. hoisting capacity at jib tip: 6t;
• Max. lifting moment 1128kN.m;
• Max. free-standing height: 41.6m; Max. working height of anchored crane: 171.5m;
• Hoisting mechanism:H37FL20-460D; power: 37kW; rope capacity:460m;
• Slewing mechanism:HPW55F1.130B/HPW55F2.130B; power: 2×5.5kW;
• Trolleying mechanism: L30FL30; power:30kW
• Types of tower crane: stationary crane with embedded outriggers, stationary crane with embedded bolts, stationary crane with under-frame and mobile tower crane.
2.Electrical control system
With PLC control, the electrical control system enjoys better reliability and safety. Produced by professional manufacturers with advanced foreign technology, the electrical elements feature service lives that are 3 or 4 times longer than that of domestic products, less faults, easy maintenance and repair as well as reliable operation.
Parameters
| Rated lifting moment (kN.m) | 800 | ||||||
| Max. lifting height (m) | Free-standing stationary crane | 41.6 | |||||
| Anchored crane | 171.5 | ||||||
| Working radius (m) | Max. working radius | 40 | |||||
| Min. working radius | 1.97 | ||||||
| Max. lifting capacity (t) | 37 | ||||||
| Hoisting mechanism | Rope fall | α=2 | α=4 | ||||
| Speed (m/min) | 45 | 90 | 30 | 60 | |||
| Lifting weight (t) | 4 | 2 | 6 | 3 | |||
| Power (kW) | 37 | ||||||
| Slewing mechanism | Speed (m/min) | 0~0.8 | |||||
| Power (kW) | 2×5.5 | ||||||
| Trolleying mechanism | Speed (m/min) | 1.6 (15°~84.5°) | |||||
| Power (kW) | 30 | ||||||
