Китай Sinotruk howo 4x2 привод 8 колес 10 тонн самосвал для

Sinotruk Howo
Chassis Model

ZZ3167M3811A/M0BA-5,ZZ3167M3811A/L0BA-5

Sinotruk Howo
Driving Type

4x2 ,6 Wheels, 2 Axles

Sinotruk Howo
Cabin

HW70--HOWO standard cabin. Basic configuration is without sleeper.
new type seat; adjustable steering wheel from up and down, front
and rear ; new type integral warm air heater with European style;
the German VDO instrument which synchronized with the world
high level heavy duty truck; road vehicles is with four point
floating suspension (front spiral spring, rear air spring) with
shock absorbers, off road vehicles is with four point floating spring
suspension + shock absorbers, each type of cabin is with transverse
stabilizing device, double lock safety belt; external sunshade; fourth
generation air conditioning, air conditioning control board is liquid
crystal display with LED lighting; with cruise; with sound warning
system for abnormal generator voltage (to prevent damage of
electronic devices); electric windows.

Sinotruk Howo
Engine

Make: SINOTRUK
Diesel 4-stroke direct injection diesel engine
Engine model: WD615.87, 290HP ;WD615.62,266HP;
Emission :Euro 2
6-cylinder in-line with water cooling, turbo-charging and intercooling
Displacement: 9.726 L

Transmission

HW19710, 10F & 2R,HW50

Steering

ZF power steering, modol ZF8118, hydraulic steering with power assitance

Front Axle

HF9,1x9000 KGS
Steering with doubleT-cross section beam

Rear Axle

HC16, 1x16000 KGS
Pressed axle housing, central single reduction with hub reduction,with
differential locks between wheels and axles.
Ratio:5.73

Propeller Shaft

Double universal joint propeller shaft with gear-shaped coupling flange

Chassis

Frame: Uprofile parallel ladder frame with section of 300x80x8mm,
reinforced subframe all cold riveted cross members
Front suspension:10 semi elliptic leaf spring, hydraulic telescopic
double-action shock absorbers and stabilizer
Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer

Brake

Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air
operating on front shaft and rear wheels
Auxiliary brake: engine exhaust brake

Electrics

Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw
Alternator: 3-phase, 28 V, 1500 W
Batteries: 2 x 12 V, 135 Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and
reverse light

Tyres

12.00R20, radial tyres with one spare tyre

Fuel Tank

300L

Cargo Body

Length:4.2M;Width:2.3M;Height:0.8-1.5M

Vehicle Size

6980x2496X3150mm
