Двигатель переменного тока
100w 0.1kw 1 фаза 220v ASD-B2-0121-F для упаковочная машина Delta Servo Мотор

100w 0.1kw 1 фаза 220v ASD-B2-0121-F для упаковочная машина Delta Servo Мотор

Категория: Двигатель переменного тока >>>
Поставщик: Guangxi,Nanning,Craftsman,Electromechanical,Equipment,Co.,Ltd.

Цена:22 298,13 ₽*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	26535.42 $*	27862.94 $*
Aug-15-2025	26312.98 $*	27628.37 $*
Jul-15-2025	22075.52 $*	23179.69 $*
Jun-15-2025	25866.40 $*	27159.54 $*
May-15-2025	22521.20 $*	23647.11 $*
Apr-15-2025	25420.97 $*	26691.93 $*
Mar-15-2025	25197.80 $*	26457.6 $*
Feb-15-2025	24974.37 $*	26223.54 $*
Jan-15-2025	24751.48 $*	25989.2 $*

Характеристики

Product name:Delta Servo drive Servo Motor 100w 0.1kw 1Phase 220v ASD-B2-0121-F For Packing Machine

* High Precision. High Response. Cost Effective.

The high-performance, cost-effective ASDA-B2 Series servo motors and drives meet the requirements for general-purpose machine control applications in the industrial automation market and enhance the competitive advantage of servo systems. The power rating of the ASDA-B2 Series ranges from 0.1kW to 3kW. The superior features of this series emphasize built-in motion control functions for general purpose applications and saving the cost of mechatronics integration. Delta's ASDA-B2 makes setting assembly, wiring,and operation convenient. In switching from other brands to Delta's ASDA-B2, the outstanding quality and features, and complete product lineup makes replacement simple and scalable.

Product Features

Implements High Precision Positioning Control

►ASDA-B2 Series servo drive supports 20-bit and 17-bit encoders. It satisfifies the demand for high-precision positioning control and stable operation with lower speed.
► Applying the encoder with a higher resolution can reduce the cogging torque and improve the motor's precision.

► Outstanding performance with higher speed: Up to 550Hz frequency response and settling time is below 1ms.
► 10ms acceleration time from -3000r/min to 3000r/min when running without a load.

Satisfifies a Variety of Industry Requirements

► Three control modes available: Built-in position, Speed, and Torque. ► High-speed differential command for high precision positioning control. ► Three notch filters are provided to suppress the mechanical resonance efficiently and make the system operate more smoothly. ► Lead friction compensation parameter is specified for the application of circular interpolation,and others to reduce the loading of the controller. ► For equipment requiring high torque output, motor protection parameters are offered to protect the mechanical system.

Offers Easy-To-Install Solution For Simple Start-Up

► ASDA-B Series share the same power cables and encoder cables for easy installation and setup without extra accessories.
► Servo motor provides brake, oil seal, and other optional confifigurations for difffferent applications.
► Separated power supply for main circuit and control circuit makes it easier to maintain the mechanism.
► 400W or above servo drives have built-in regenerative resistors, which simplify wiring and reduce the installation cost.
► Individual connectors for analog signal output, also simplififies the wiring.

Fulfifills Easy-To-Use Requirements For Versatile Operation

► User-friendly motor sizing software allows users to select the motor.
► ASDA-Soft confifiguration software (tuning software) is provided to meet performance requirements quickly.
► Easy-to-use digital keypad is ideal for setting parameters and enables users to directly monitor the servo drive and servo motor.
► Specifific software communication cable ASD-CNUS0A08 (Optional) can improve communication quality and convenience of operation.

Provide 2 m, 3 m, 5 m, 10 m, 15 m...If necessary, please contact the customer service staff.

Detailed Images

Product model

Servo driver model	Servo motor model
ASD-B2-0121-B	ECMA-C20401ES	ECMA-C21010RS
ASD-B2-0121-F	ECMA-C20401FS	ECMA-C21010SS
ASD-B2-0221-B	ECMA-C20401GS	ECMA-E21310RS
ASD-B2-0221-F	ECMA-C20401HS	ECMA-E21310SS
ASD-B2-0421-B	ECMA-C20602RS	ECMA-E21315RS
ASD-B2-0421-F	ECMA-C20602SS	ECMA-E21315SS
ASD-B2-0721-B	ECMA-C20604RC	ECMA-C21020RS
ASD-B2-0721-F	ECMA-C20604RS	ECMA-C21020SS
ASD-B2-1021-B	ECMA-C20604SS	ECMA-E21320RS
ASD-B2-1021-F	ECMA-C20804R7	ECMA-E21320SS
ASD-B2-1521-B	ECMA-C20804S7	ECMA-G21306RS
ASD-B2-1521-F	ECMA-C20807RS	ECMA-G21306SS
ASD-B2-2023-B	ECMA-C20807SS	ECMA-G21309RS
ASD-B2-2023-F	ECMA-C20807R6	ECMA-G21309SS
ASD-B2-3023-B	ECMA-C20907RS
ASD-B2-3023-F	ECMA-C20807RC

Scenarios &features

Scope of application: Sawing Machines;Food Packaging Machinery; Electric Discharge Machines (EDM);Cutting Machines;Transporting and Conveying Equipment;Feeding Machine; High Speed Shrink Labelling Machine; TFT Panel Cutting; IC Packaging Machine; Discharge Processing Machine; Precision Engraving Machine; Printing Equipment; Textile Equipment; Etc.Delta Servo drive Servo Motor 100w 0.1kw 1Phase 220v ASD-B2-0121-F For Packing Machine
