Коммуникационный электромагнитный расходомер жидкости
- Категория: Расходомер >>>
- Поставщик: Beijing,Ifan,Peng,Instrument,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 357.89 $* | 375.94 $* |
| Aug-20-2025 | 354.88 $* | 372.54 $* |
| Jul-20-2025 | 297.42 $* | 312.45 $* |
| Jun-20-2025 | 348.74 $* | 365.21 $* |
| May-20-2025 | 303.75 $* | 318.41 $* |
| Apr-20-2025 | 342.41 $* | 359.15 $* |
| Mar-20-2025 | 339.95 $* | 356.81 $* |
| Feb-20-2025 | 336.1 $* | 353.47 $* |
| Jan-20-2025 | 333.42 $* | 350.61 $* |
Характеристики
Product Description
Specification
Item | slurry flow meter |
Applicable pipe size | DN 15-800 (1/2'' to 31-1/2'') |
Applicable media | liquid with conductivity > 5 uS / cm |
Accuracy | 0.5%FS, 1.0%FS |
Process connection | flange, ANSI / GB / JIS, 1.0MPa, 1.6MPa, 4.0MPa, 16MPa optional |
Processing temperature | -20 to 150°C, according to lining material |
Ambient condition | -40 to 80°C, relative humidity <95% |
Power supply | AC220V, 50Hz / DC24V / battery |
Display | backlightLCD |
Operation | 4 light touch buttons |
Signal output | 4-20mA, loading resistance 750Ω, |
pulse, 0-3kHz, 5V, | |
RS485 | |
Consumption | <8W |
Cable inlet/outlet | M20*1.5 |
Protection | transducer IP68, converter IP65 |
Tube material | carbon steel, stainless steel optional |
Lining material | PTFE, rubber, polyurethane, F46, Fs optional |
Electrode material | stainless steel, Hastelloy B, Hastelloy C, Titanium, Tantalum, Platinum optional |
Grounding | made into a third electrode, same material with electrode |
Industries | chemical, environmental, metallurgical, pharmaceutical, papermaking, water supply and drainage, etc. |
Packing & Delivery
AF Series Digital water electromagnetic flow meter sewage magnetic flowmeter Smart electromagnetic flowmeter of LD series is oriented for conductive liquid with conductance higher than 5 us/cm,It can be used on measure the volume flow of conductive fluid in a closed pipeline.It is composed of sensor and converet and two versions are avaliable:compact version and separte version.it is windely applied in the flow measurement and control in the filied od chemical
and petroleum industry ,metallurgy indistry,water and waste water,agriculture and irrigation,papper making,food and beverage industry and pharmaceutical industry.
and petroleum industry ,metallurgy indistry,water and waste water,agriculture and irrigation,papper making,food and beverage industry and pharmaceutical industry.
Features.
--anti abrasive hard rubber lining material .
--electric conductivity of medium can be used for detection of product change.
--no additional pressure loss magnetic flow meter.
--no moveable parts and long working life.
--site digital LCD displays instantaneous flow, accumulative flow, flow rate.
--various output method, like 4-20mA, 0-5V, RS485 and pulse.
--compact, split and plug-in types optional.
--change the grounding as the third electrode.
