Домашний стабилизатор переменного тока напряжения

Категория: Voltage Regulators\/Stabilizers >>>
Поставщик: Hangzhou,Maixi,Electronics,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.31 $*	0.48 $*
Aug-18-2025	0.69 $*	0.97 $*
Jul-18-2025	0.68 $*	0.83 $*
Jun-18-2025	0.38 $*	0.91 $*
May-18-2025	0.2 $*	0.56 $*
Apr-18-2025	0.68 $*	0.2 $*
Mar-18-2025	0.38 $*	0.87 $*
Feb-18-2025	0.19 $*	0.43 $*
Jan-18-2025	0.2 $*	0.75 $*

Характеристики

Product Description

Main Features:

•Stepless voltage regulation over a wide range
•The high output voltage accuracy (1.5%)

•Surge protection voltage stabilizer
•Protection against short circuit and overheating

•Differentiation and fault indication
•Informative LCD-display

•Modern design and surge protection up to 300 V

•Microprocessor control
•High speed regulation

•The wide input voltage range

•The multistage defense

Home Power ac Stabilizer Voltage Stabilizer 5000va

Paramenters

Technology	Relay Control System+Programmed control computerized+control algorithm relay"Cross zero"
Input Voltage	AC140-260V
Output Voltage	220V±1.5% or 3.5%
Phase	Single Phase
Frequency	50-60Hz
Adjust Time	<1sec.(against 10% input voltage deviation)
Protection Overvoltage	<250±2V
Protection Lack Voltage	＜185V±2V
Delay	8 second
Temp. Protection	110℃±10℃
Ambient Temp.	-10~+45℃
Relative Humidity	<90%
Waveform Distortion	No additional wave form distortion
Efficiency	>95%
Dielectric Strength	1500V/min
Insulation Resistance	≥5MΩ

Model	Power	Unit(pcs)	Package Size(mm)	G.W(KG)
AVR-500	500W	8	575275380	19.52
AVR-1000	1000W	8	575275380	23.12
AVR-2000	2000W	4	355305450	21.92
AVR-3000	3000W	4	355305450	23.32
AVR-5000	5000W	2	515420310	22.72
AVR-8000	8000W	2	460265310	15.90
SDR-10000	10000W	1	460265310	18.70

Product Details

Packing & Delivering

Application

Customer Reviews

Highly Recommended

FAQ

Q. How to select Servo Voltage Stabilizer?

A. When you select any stabilizer it requires some data as follows:
> Input Voltage range
> Output Voltage range
> KVA rating.
> Type of load: balance/unbalance.
> Type of voltage: balance / unbalance.
> Type of protection required.
> Type of cooling: air / oil

Q. Which protection to use in your Stabilizer?
A. We provide protection against bypass, short circuit, over load, over voltage/under voltage and also if customers have any specific requirement.

Q. What is the efficiency of your Stabilizer?
A. The efficiency of our Stabilizer is more than 97% in comparison with other type available in the market.
