Items

Unit

Parameters

Max. paving width

m

4.2

Max. paving thickness

mm

200

Paving speed

m/min

30

Travel speed

km/h

3.6

Theoretical Productivity

t/h

300

Hopper Capacity

t

12

Gradeability

%

20

Pavement evenness

mm/3m

2

Transverse levelling accuracy

%

±0.03

Centre crown ratio

%

0~+3

Engine model

BF4M2012C

Engine power

kW

75

Engine speed

r/min

2200

Machine weight

t

12

Dimension

mm

5535×1800×3580

Vibrator speed

r/min

0~1470

Screed heating

electric heating

Auger and conveyor control

Automatic Control by Ultrasonic Sensors

Automatic levelling control

Simulation control of electronic automatic leveler
