Ali baba каталог производителей товары платформа 4x2 буксировочный эвакуатор на

Essential information

Model:

ZZ1167G471CD1

Driving mode:

4X2

Engine:

Foton Cummins isf3.8s4r168

Rear axle speed ratio:

4.33

Body width:

2300mm

Tread:

Front track: 1801mm; rear track: 1796mm

Rated load:

9.9ton

Maximum speed:

95KM/h

Tonnage class:

Medium card

Front suspension / rear suspension:

1.24/2.505rice

Type:

chassis

Wheelbase:

4700mm

Transmission case:

WanLiYang wly6t53

Body length:

8400mm

Body height:

2500mm

Vehicle weight:

5860kg

Total quality:

15.795ton

Approach / departure angle:

17/20degree

Engine

Engine:

Foton Cummins isf3.8s4r168

Engine is commonly known as:

Fukang 3.8

Fuel type:

diesel oil

Displacement:

3.76L

Maximum output power:

125KW

Torque:

600N. M

Rated speed:

2600RPM

Engine brand:

Foton Cummins

Cylinder number:

4

Cylinder arrangement:

Inline

Emission standard:

Four China

Maximum horsepower:

168horsepower

Maximum torque speed:

1300-1700RPM

Engine type:

Vertical, in-line four cylinder, water-cooling, four stroke, electronic direct injection

cargo body parameter

Container form:

chassis

cargo  length*width*height:

6250X2300X550mm

Cab parameters

Cab:

2080 Half height top

Number of passengers allowed:

3people

Number of seats:

Platoon half

Transmission case

Transmission case:

WanLiYang wly6t53

Shift mode:

Manual

Reverse number:

1individual

Gearbox brand:

Wan Liyang

Forward gear:

6block

tyre

Tire size:

8.25R20/9.00R20

Tires:

6individual

tank

Tank material:

Aluminium alloy

Tank capacity:

150L

chassis

Allowable load of front axle:

5850KG

Allowable load of rear axle:

9945KG

Number of springs:

11/9+7

Rear axle Description:

1080Strengthening type

Rear axle speed ratio:

4.33

One for two folding flat top:

Operating device

Bilateral linkage

A wire rope

25 meters

Hydraulic capstan

1X4T

Hold-all

1-2 (made according to chassis space)
