Усилитель высокой мощности для глушителя GSM DCS 3G LTE 5 8G 2 4G GPS C band
- Категория: Усилитель >>>
- Поставщик: Shenzhen,Yonlit,Telecom,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.54 $* | 0.16 $* |
| Aug-19-2025 | 0.18 $* | 0.33 $* |
| Jul-19-2025 | 0.30 $* | 0.1 $* |
| Jun-19-2025 | 0.96 $* | 0.22 $* |
| May-19-2025 | 0.30 $* | 0.64 $* |
| Apr-19-2025 | 0.41 $* | 0.61 $* |
| Mar-19-2025 | 0.72 $* | 0.66 $* |
| Feb-19-2025 | 0.44 $* | 0.18 $* |
| Jan-19-2025 | 0.88 $* | 0.29 $* |
Характеристики
Product Description
Feature
* This high power amplifier can be used for Jammer, Lab equipment, etc.
* Efficiency is more than 30% for 45W
* Over-high VSWR to avoid or reduce the damage from any mismatch
* Over-high temperature protection, automatically shutdown when temp over than 75℃, auto-restart when temp less than 50℃
* Standard DB15 serial port, DB9 Parallel RS485 as optional(China Mobile Protocol).
* Pout is stable over -20~65℃
* Efficiency is more than 30% for 45W
* Over-high VSWR to avoid or reduce the damage from any mismatch
* Over-high temperature protection, automatically shutdown when temp over than 75℃, auto-restart when temp less than 50℃
* Standard DB15 serial port, DB9 Parallel RS485 as optional(China Mobile Protocol).
Main Specification
Frequency range:
851-894MHz/ 925-960MHz/ 1805-1880MHz/ 1930-1990MHz/ 2110-2170MHz/ 2620-2690MHz/ 2400-2500MHz
Customized
Output Power
45W (46.5dBm)
Power Supply
28V DC
Dimension
180*90*25mm (Exclusive Connector)
Contact us
For more details, please contact us. Thank you.
