125L Electric Portable Cement Mixer/Mini Mobile Concrete Mixer electric12bag Machine Price Philippines/industrial mixing machine

1. Production Application

LONTA CM SEIRES Mini Concrete mixer has entirely changed the traditional way of mixing concrete by hand. It provides an easy and quick way to mix of sand or gravel and water. Depending on the application,  A portable concrete mixer consists of a motor, a rotating drum, blades,stands etc.



2 Specification Sheet



TYPE	CM46	CM70	CM125	CM140
Motor	230v/50hz	230v/50hz	230v/50hz	230v/50hz
Power(W)	300w	375w	550	550
Motor no load speed(min)	2950	1450	2950	2950
Drum Speed	35	50	34	34
Drum Capacity	46	50	125	140
Dia of Drum (mm)	420	420	560	560
Dia of Drum Opeining(mm)	270	270	375	375
Packing Size(mm)	585*585*340	645*542*320	820*705*390	810*710*425
G.W./N.W.	28/25	30/28	52/48	57/52
Loading amount
20GP	259pcs	250pcs	138pcs	110pcs
40HQ	558pcs	600pcs	310pcs	270pcs



TYPE	CM160	CM180	CM200	CM220
Motor	230v/50hz	230v/50hz	230v/50hz	230v/50hz
Power(W)	650	650	800	800
Motor no load speed(min)	2950	2950	2950	2950
Drum Speed	32	32	32	32
Drum Capacity	160	180	200	220
Dia of Drum (mm)	620	620	620	620
Dia of Drum Opeining(mm)	400	400	400	400
Packing Size(mm)	840*710*405	840*720*425	840*720*475	840*720*505
G.W./N.W.	58/53	61/56	64/59	66/61
Loading amount
20GP	110pcs	110pcs	108pcs	88pcs
40HQ	264pcs	264pcs	240pcs	220pcs





LONTA CM SERIES CONCRETE MIXER FEATURES



1.Special casting or steel-sheet gear ring made in one piece

2. durable steel frame and easily portable

3.Large wheels for stability and easily movement

4.Using wleding robot to weld and Large drum diameter for excellent mixing results

5.Swivels and tilts 360 ° for easy and complete discharge

6.Driving shaft mounted on sealed ball bearing
