Китай производитель завод прямой заказ 135w полу гибкие
- Категория: Solar Panels >>>
- Поставщик: Shenzhen,Sungold,Solar,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.2 $* | 0.80 $* |
| Aug-20-2025 | 0.0 $* | 0.46 $* |
| Jul-20-2025 | 0.53 $* | 0.15 $* |
| Jun-20-2025 | 0.58 $* | 0.34 $* |
| May-20-2025 | 0.6 $* | 0.76 $* |
| Apr-20-2025 | 0.17 $* | 0.11 $* |
| Mar-20-2025 | 0.30 $* | 0.1 $* |
| Feb-20-2025 | 0.96 $* | 0.84 $* |
| Jan-20-2025 | 0.59 $* | 0.37 $* |
Характеристики
Product Parameters
Technical features | ||||||||||||
Component Model | SGM-FL-150W | SGM-FL-135W | SGM-FL-120W | SGM-FL-110W | SGM-FL-80W | SGM-FL-60W | ||||||
Peak power(WP): | 160W | 135W | 120W | 110W | 80W | 60W | ||||||
Voltage at Pmax(Vmp): | 25.5V | 23.2V | 20.9V | 18.6V | 19.8V | 19.8V | ||||||
Current at Pmax(Imp): | 5.97A | 5.97A | 5.97A | 5.97A | 4.04A | 3.13A | ||||||
Open circuit voltage(Voc): | 30.1V | 27.4V | 24.6V | 21.9V | 23.4V | 23.4V | ||||||
Short circuit current(Isc): | 6.32A | 6.32A | 6.32A | 6.32A | 4.28A | 3.32A | ||||||
Solar cells: | SUNPOWER 3.46W | |||||||||||
Min power tolerance: | ±3% | |||||||||||
Max System Voltage(VDC): | 45V DC | |||||||||||
Module Efficiency: | 22.60% | |||||||||||
Temperature Coefficient of Pmax: | -0.24%/℃ | |||||||||||
Temperature Coefficient of Voc: | -0.25%/℃ | |||||||||||
Temperature Coefficient of ISC: | -0.06%/℃ | |||||||||||
Nominal Operating Cell Temperature: | 45+/-2℃ | |||||||||||
Data under standard testing conditions(STC):1000W/M²; 1.5AM | ||||||||||||
Mechanical Characteristics | ||||||||||||
Type of Connector: | MC4 Connector | |||||||||||
Dimension A x B x C: | 1460*540*3mm | 1330*540*3mm | 1200*540*3mm | 1070*540*3mm | 840*540*3mm | 625*540*3mm | ||||||
Weight: (kg) | 2.86KG | 2.63KG | 2.34KG | 2.18KG | 1.70KG | 1.31KG | ||||||
No.of mounting Holes in Frame: | 6 * φ6mm holes | |||||||||||
Junction Box(protection degree): | PV-HX021 | |||||||||||
Qualification Test Parameters | ||||||||||||
Dielectric Insulation Voltage: | 45V DC | |||||||||||
Operating Temperature: | （-10℃-+60℃） | |||||||||||
Warranty:For 1 year and service life of 5 years. | ||||||||||||
Product Details
Our Advantages
Client Feedback
About Us
Shenzhen Sungold Solar Co., LItd
Sungold Advantages:
-The professional producing experience of solar panel for 13 years
Accumulating the experience for more than a decade,Sungold has become a company with mature technology and management system
-Outstanding quality
With the certificates of ISO, RoHS, CE, etc. We professionally provide high quality products with automated production line.
-Professional techniques and service
Every Sungold product is crafted according to the needs of customer, also, the service we do is all for customer.
-The professional producing experience of solar panel for 13 years
Accumulating the experience for more than a decade,Sungold has become a company with mature technology and management system
-Outstanding quality
With the certificates of ISO, RoHS, CE, etc. We professionally provide high quality products with automated production line.
-Professional techniques and service
Every Sungold product is crafted according to the needs of customer, also, the service we do is all for customer.
Exhibition & Certificate
Logistics Transportation
FAQ
1)Q:The price is too expensive,why?
We choose the best material to make. All SunPower A grade cells are imported from the USA, and we insist on the development of quality.
2)Q:What is the payment term?
100% T/T in advance 30% T/T in advance balance before shipment when your order over 10000usd
3)Q:Why is the delivery time too long?
It depends on your quality of order and product type: If you only need a sample, we can send you soon.
4)Q:What is mono and poly panels?
The panel adopts mono-crystalline and poly-crystalline cells.
5)Q:What is the different between mono and poly?
The cells conversion efficiency is different. The mono cell is higher than poly one. Mono is 20.6%, and poly is 18.3%, so mono panel is more expensive than poly panel.
6)Q: What is the warranty of the panel?
Mono panel and poly panel has 10 years warranty. Flexible panel has 1 year warranty and 5 year service time. Customers told a panel was bought in 2012 is still working.
7)Q: What is the package of the flexible panel?
1 pcs is put in a bubble bag and one carton and 10pcs are put in bigger carton, then wooden pallet.
8)Q: How many workers in Sungold?
Almost 300.
9)Q: Do you have any certificates on the panels?
CE, ROHS and ISO.
10)Q: Can you do OEM for my panels?
Yes, we support OEM and ODM.
We choose the best material to make. All SunPower A grade cells are imported from the USA, and we insist on the development of quality.
2)Q:What is the payment term?
100% T/T in advance 30% T/T in advance balance before shipment when your order over 10000usd
3)Q:Why is the delivery time too long?
It depends on your quality of order and product type: If you only need a sample, we can send you soon.
4)Q:What is mono and poly panels?
The panel adopts mono-crystalline and poly-crystalline cells.
5)Q:What is the different between mono and poly?
The cells conversion efficiency is different. The mono cell is higher than poly one. Mono is 20.6%, and poly is 18.3%, so mono panel is more expensive than poly panel.
6)Q: What is the warranty of the panel?
Mono panel and poly panel has 10 years warranty. Flexible panel has 1 year warranty and 5 year service time. Customers told a panel was bought in 2012 is still working.
7)Q: What is the package of the flexible panel?
1 pcs is put in a bubble bag and one carton and 10pcs are put in bigger carton, then wooden pallet.
8)Q: How many workers in Sungold?
Almost 300.
9)Q: Do you have any certificates on the panels?
CE, ROHS and ISO.
10)Q: Can you do OEM for my panels?
Yes, we support OEM and ODM.
