High quality hot sale steel sound barrier fence,noise barrier wall,highway and railway noise barrier price for road,

1. Material

1)Metal type: acrylic sheet,Galvanized metal sheet, aluminum sheet,stainless steel sheet;

2) Appearance: shutter type, perforated holes type.

 3)Colors: Clear, lake blue, green, blue, opal, brown, silvery gray, red (Other colors can be ordered as per special request ).

2. Noise  barrier Metal panel Sizes:



panel thickness	40mm,50mm,60mm,80mm, 100mm,120mm
Each Panel size	2500x500x80mm, 2500x500x100mm, etc.
Noise Barrier metal plate thickness	0.5-1.2mm
Noise Barrier panel H-post	100x100x6x8mm, 125x125x6.5x9mm, 150x150x7x10mm, 175x175x7.5x11mm,etc.
Noise Barrier flange plate	250x250x10, 300x300x10, 350x350x10, 400x400x10mm,etc.



PC/PMMA SHEET
PANEL HEIGHT		HEIGHT		SHEET THINCKNESS		LIGHT TRANSMITTANCE
0.5m 1.0m 1.5m		2.0m 2.5m 3.0m 4.0m		8mm 10mm 12mm 15mm		≥80%

3.The fence panel application:

Sound barrier, between the source and receiver inserts a facilities, make the sound waves spread

has a significant additional damping, so as to abate the noise in the receiver in a certain area,

such facilities are called noise barrier. It can be divided into traffic noise barriers, the equipment

noise attenuation of noise barriers, industrial factory boundary noise barriers.

4.Payment terms: T/T,PAYONEER, WESTERN UNION.

   Trade term: EXW or FOB TIANJIN

5.supply ability: 2000 square meter/day

6.packing detail:

packaged with both side PE film or as you requirement;
