Профессиональные PCBA OEM услуги micro sd карта памяти pcba
US $0.12-$1.00
Сетевая плата управления M02C OEM android lcd lvds 32G 8 1 OS со встроенной SIM-картой
- Категория: Блок печатных плат >>>
- Поставщик: Clientop,Technology,Co.,Ltd.,(Shenzhen)
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.71 $* | 0.78 $* |
| Aug-17-2025 | 0.8 $* | 0.68 $* |
| Jul-17-2025 | 0.32 $* | 0.11 $* |
| Jun-17-2025 | 0.74 $* | 0.43 $* |
| May-17-2025 | 0.84 $* | 0.11 $* |
| Apr-17-2025 | 0.0 $* | 0.30 $* |
| Mar-17-2025 | 0.67 $* | 0.87 $* |
| Feb-17-2025 | 0.11 $* | 0.2 $* |
| Jan-17-2025 | 0.52 $* | 0.32 $* |
Характеристики
Product Description
M02C Network OEM android lcd lvds control board 3+32G android 8.1 OS embedded 4g sim board
M02C is a high performance ,low consumption solution base on MTK12 Nano platform，Supports android 8.1OS ,compatible with LVDS LCD panels\u007F
8 core CPU：4 *core A73,2.0G + 4 *core A53,2.0G
GPU:ARM Mali-G72 MP3 reach to 800MH
Memory: 3GB+32GB
Support connecting with LTE-FDD / LTE-TDD / WCDMA,etc.
multiple data network service types:
LTE：Cat-7 DL / Cat-13 UL
Unicom 3G&4G network(2G calling is not supported ）
Support WiFi ,BT4.2, GPS；
Board features
★\u007F Vertical/landscape\u007Fdisplay，support\u007F180\u007Fdegree\u007Frotation\u007F
★\u007F Support\u007Fpanel\u007Fsplitting\u007Fdisplay\u007F
★\u007F Auto\u007Floop\u007Fdisplay\u007Fonce\u007Fpower\u007Fon\u007F
★\u007F Timing\u007Fswitch\u007F
★\u007F Long\u007Fwords\u007Fsubtitle\u007Frolling\u007Fdisplay\u007F,the\u007Ffront\u007Fsize\u007Fand\u007Fscrolling\u007F,marquee\u007Fcan\u007Fbe\u007Fadjusted\u007F
★\u007F Files\u007Fcould\u007Fbe\u007Fcopy\u007For\u007Fdelete\u007Fon\u007Fthe\u007Fboard\u007Fdirectly,support\u007FUSB\u007Ffile\u007Fupdate\u007F
★\u007F Support\u007FUSB\u007Fdisplay\u007F ，hot\u007Fplug，easy\u007Fcontent\u007Fupdating\u007F
★\u007F Audio&video\u007Fformat：MPEG-1,\u007FMPEG-2,\u007FMPEG-4,\u007FH.263,\u007FH.264,\u007FAVS, VC-1,\u007FVP8,\u007FMVC\u007Fetc.\u007F
★\u007F Play\u007Fmode：single\u007Floop、folder\u007Floop、root\u007Floop\u007F
★\u007F Picture\u007Fdisplay：rotating、zooming、translation、PPT、background\u007F music.\u007F
★\u007F Audio\u007Fmode：left\u007Fchannel、right\u007Fchannel、stereo\u007F
★\u007F OSD\u007Flanguage：Chinese,English,\u007Fetc.\u007F
★\u007F Calendar\u007F
★\u007F High\u007Fbrightness、high\u007Fdefinition\u007F
★\u007F USB\u007Fprogramming
★\u007F Support\u007Fpanel\u007Fsplitting\u007Fdisplay\u007F
★\u007F Auto\u007Floop\u007Fdisplay\u007Fonce\u007Fpower\u007Fon\u007F
★\u007F Timing\u007Fswitch\u007F
★\u007F Long\u007Fwords\u007Fsubtitle\u007Frolling\u007Fdisplay\u007F,the\u007Ffront\u007Fsize\u007Fand\u007Fscrolling\u007F,marquee\u007Fcan\u007Fbe\u007Fadjusted\u007F
★\u007F Files\u007Fcould\u007Fbe\u007Fcopy\u007For\u007Fdelete\u007Fon\u007Fthe\u007Fboard\u007Fdirectly,support\u007FUSB\u007Ffile\u007Fupdate\u007F
★\u007F Support\u007FUSB\u007Fdisplay\u007F ，hot\u007Fplug，easy\u007Fcontent\u007Fupdating\u007F
★\u007F Audio&video\u007Fformat：MPEG-1,\u007FMPEG-2,\u007FMPEG-4,\u007FH.263,\u007FH.264,\u007FAVS, VC-1,\u007FVP8,\u007FMVC\u007Fetc.\u007F
★\u007F Play\u007Fmode：single\u007Floop、folder\u007Floop、root\u007Floop\u007F
★\u007F Picture\u007Fdisplay：rotating、zooming、translation、PPT、background\u007F music.\u007F
★\u007F Audio\u007Fmode：left\u007Fchannel、right\u007Fchannel、stereo\u007F
★\u007F OSD\u007Flanguage：Chinese,English,\u007Fetc.\u007F
★\u007F Calendar\u007F
★\u007F High\u007Fbrightness、high\u007Fdefinition\u007F
★\u007F USB\u007Fprogramming
CPU | MTK12NANO platform, 4*core A73 with 4* core A53,Frequency 2.0Ghz | ||||
GPU | Mali-G72 | ||||
Ram | 3GB | ||||
Operation system | Android 8.1 OS | ||||
Memory | 32GB | ||||
Resolution | 1920*1080 | ||||
4G network | embedded 4G module, SIM card Plug and play | ||||
Picture format | BMP、JPEG、PNG、GIF etc. | ||||
Video format | MPEG2,MPEG4,AVC1,WMV3,VP8 | ||||
Network | Ethernet,Wifi,BT4.1,4G. | ||||
System update | network update,USB update, pc update | ||||
Power | 12V DC input | ||||
Interface output | LVDS | ||||
RTC | support | ||||
Other functions | Integrated with 4G funciton in board, widely compatible with 4G cards. | ||||
Applications
M02C is Integrating USB/LVDS/Ethernet /4G/WIFI/BT4.1 functions in one board .This smart android 8.1 OS lcd controller board supports multiple extension modules, simplify the design of the whole machine, is perfectly suitable for all kinds industrial control area, could be widely applied for retailing service, smart cashiers, wisdom dovernment affairs serives, self-service kiosk,self-service delivery locker,and smart sharing industries,etc.
Packing & Delivery
Packing
Standard export package: Bubble bag+hard paper carton
Delivery
3 days after the payment.The transport mode base on customer's requirment
Our Company
Clientop Industrial Co.,Ltd
Clientop Industrial Co.,Ltd ,a company with full experience in producing LCD advertising products and LCD kits.also a leading company of this line for more than 10year,with good quality and competitive price as well as very good service.
In order to make sure clients can receive qualified iterm, we do 100%product test before shippment.
We provide wholelife professional after-sale technical support as well whose purpose is try our best to provide best shopping experience for you!
FAQ
1 . About the quality
All of our product will be testing before shipping . So you can be assured the quality of our products .
However, If you found any problem after received the goods , Please feel free contact to us .
We will be willing to deal with your problem at the first time .
2. About the payment
Sample order :A Aliexpress B Paypal C Union Western
Large order: HSBC bank (Company account)
3. About warranty and Return
We offer one year warranty for most of our products and professional technical support .
Please contact us if there are any problems and we will do my best to fix it out. Here is our misrepresented & unsatisfied merchandise policy.
-- 1. We accept returns for replacement or refund within 5 days after receipt of item(s). Items MUST be in their original condition, not worn or altered.
-- 2. We do not reimburse the return shipping charge. Refunds will be for the original price paid, and will be issued within 7 business days after receipt of the return.
