50 Вт AC85-265v с радаром pir IP67 пульт дистанционного управления диммером для pwm светодиодный
- Категория: Переключатель источника питания >>>
- Поставщик: Huizhou,Jinhetai,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 7.51 $* | 7.1 $* |
| Aug-17-2025 | 7.78 $* | 7.28 $* |
| Jul-17-2025 | 6.60 $* | 6.54 $* |
| Jun-17-2025 | 7.75 $* | 7.0 $* |
| May-17-2025 | 6.64 $* | 6.95 $* |
| Apr-17-2025 | 7.80 $* | 7.70 $* |
| Mar-17-2025 | 7.67 $* | 7.98 $* |
| Feb-17-2025 | 7.95 $* | 7.82 $* |
| Jan-17-2025 | 7.79 $* | 7.95 $* |
Характеристики
Product Description
50W AC85-265v with radar pir IP67 remote dimmer module for pwm control dimming led driver
name | KHT-AC 50W | KHT-AC 100W |
output voltage | DC20-36V | DC24-36V |
input voltage | AC85-265V | AC85-265V |
power | Max 50W(85-180V) Max 65W(180-265V) | Max 100W(85-180V) Max 120W(180-265V) |
output current | 0.15-1.5A | 0.15-3.3A |
input current | Max 1.2A | Max 1.7A |
surge protection | 4KV | 4KV |
PF | 0.95-0.99 | 0.95-0.99 |
efficiency | Max 90% | Max 90% |
IP | 67 | 67 |
Dimming range | 10%-100% | 10%-100% |
OVP | Max 60V | Max 60V |
working temperature | -30~+65 | -30~+65 |
Features
* Lightning protection level: 4KV differential mode, 10KV common mode
* Constant power design, adjustable output programming and automatic adaptation of output voltage.
* Short circuit, over voltage, over temperature protection
* Support daylight auto-sensing
* Support NEC infrared receiving protocol
* Supports custom programming control
* Working environment: -30 ℃ ～ + 65 ℃
Function | Overview |
Radar induction | Lights up automatically when a moving object approaches |
Automatic power reduction (time control) | Power down period can be set by our company's dedicated remote control |
Programmable remote control | Please refer to our programmable remote control manual |
Over temperature protection | Automatically reduce power when drive power temperature is too high |
Light control function | Lights off automatically during the day and lights up at night |
Morning light function | Automatically light for a period of time in the morning (can be set by programming remote control) |
Application
* Street lights
* Spotlight
* Industrial and mining lights
* Spotlight
* Industrial and mining lights
Details Images
Similar products
KHT-3.2V 15A Linear solar controller
Voltage: 3.2-6.4V
Charging current: 15A, maximum 25A
Discharging current: 8A, maximum 10A
Power: 30W
With charge management
Can set parameters remotely
Automatic power reduction
Can be connected to radar and human induction With memory function
Remote control current adjustment
Other Related Products
KHT-FTSY-612-40W （Boost）
Input voltage: 6-12V
output voltage: 25 - 35V
output current: 1A(adjustable)
boost conversion efficiency: 95%
maximum charging current: 8A
reset time after charging: 30s
after dark light delay: 5s
after dawn Lamp delay: 5s
remote control distance: 0 - 15m
board size: 62 × 52mm
Function:
Remote control, charge indication, timing function, automatic power down, charge management function, externally connected to human body induction
KHT-PY36-30W （Flat voltage）
Working current: 0- 5A constant current
suitable power: 0- 30W suitable battery: 3.2 - 6.4V human induction distance: more than 10 meters, 30s or so
human induction delay time: about 30s
between lamp beads voltage: 3- 6v
board size: L62 × W32 × H4mm
Function:
Timing dimming function, remote control port communication, remote control port communication, external human body sensing function, automatic power down, time control and drop power, voltage drop power, increase in lighting duration in cloudy and rainy days, charge management function, overcharging protection
KHT-PY32-10W （Flat voltage）-Sen Ba
Working current: 0-3A constant current
applicable power: 0-10W applicable battery: 3.2 - 3.7V human body induction distance: more than 10m, 30s
human body induction delay: about 30s
between the lamp beads voltage:3V
board size L62 × W32 × H4mm.
Function:
the timing light adjusting function, the remote control port communication, the remote control port communication, the human body induction function, the automatic power down power, the time control drop power, the voltage drop power, the cloudy rainy day lighting time period are increased,
KHT-SY-30W-Sen Ba
Input voltage 6.4 - 11.1V (2 or 3 series boost circuits)
maximum power 30W
efficiency 92-95%
discharge circulation 3A external human induction remote control adjustment time and brightness
KHT-MCU-V1
Size: 15*15MM
input: DC5-12V
acousto-optic control module, illuminance is 10-20 LUX, receive sound signal, output is high and low level delay 40 seconds plus or minus 5 seconds.
Size: 15*15MM
input voltage 5 V-12V
with photosensitive
built-in MCU
human induction: Senba
distance: 10 -12m
Size: 20*20MM
input voltage: 5 -12V
MCU external
human induction: Senba
distance: 10-12m
KHT-YT3-25W
with digital display
Actual watts: 3W
discharge current: 0.9A
current limiting resistance: 1R*4
remote control distance: 0 --15m
optical control delay: 5S
automatic mode: 10 minute drop 2%
LED specification: 5730-56
LED luminous surface size: 68 x 32
lamp board size: 90 x 55
KHT-YT3-40W
with digital display
Actual wattage: 5.2W
discharge current: 1.6A
current limiting resistance: 1R*4
remote control distance: 0-15m
light control delay: 5S
automatic mode: 10 minutes drop 2%
LED specification: 5730-90
LED luminous surface size: 82*38
lamp board size: 108*71.
KHT-YT3-60W
with digital display
Actual watts: 7W
discharge current: 1.6A
current limiting resistance: 1R*2 0.5R*2
remote control distance: 0- 15m
optical control delay: 5S
automatic mode: 10 minutes drop 2%
LED specification: 5730-120
LED luminous surface size: 98 x 45 lamp board size: 112 x 74
KHT-YT3-100W
with digital display
Actual wattage: 10W
discharge current: 1.6A
current limiting resistance: 0.2 R * 4
remote control distance:0-15 m
light control delay:5 S
automatic mode:10minute drop 2%
LED specification:5730-224
LED light-emitting surface size:125 * 63
lamp panel size:147 * 102
KHT-YT3-100W
with digital display
Actual wattage:16.3W
Discharge current:5A
Current limiting resistance:0.1R*5 Remote control distance:015m control delay:5S
Automatic mode:10 min. drop 2%
LED specification:5730-323
LED light emitting surface size:160*80
Lamp plate size:187*113.
Housing: Chuanghe Jubao, timing function, electricity indication, charging indication, infrared remote control, intelligent power reduction, charge and discharge management, can be customized as required.
KHT-YT3- 120W
Actual wattage: 11.2 W
Discharge current: 3.5A
Current limiting resistance: 0.1R * 4
Remote distance:0-15M
Light control delay: 5S
Memory function: Yes
Automatic mode: 10 minutes drop 2%
Battery category: 3.2 V60AH
LED specification:5730-120
Lamp panel size:257 * 121
KHT-YT3- 90W
Actual wattage: 8W
discharge current: 2.5A
current limiting resistance: 0.2R*4 remote control distance: 0 -15m
optical control delay: 5S
memory function: Yes
automatic mode: 10 minutes drop 2%
battery category: 3.2V30AH
LED specification: 5730 -90
lamp board size: 231*107
KHT-YT3- 60W
Actual wattage: 5.1W
Discharge current: 1.6A
Current limiting resistance: 0.5R * 4
Remote distance:0-15M
Light control delay: 5S
Memory function: Yes
Automatic mode:10 minutes drop 2%
Battery category: 3.2 V30AH
LED specification:5730-60
Lamp panel size:208 * 105
Banana-fan type street light
1. With charge and discharge management
2. Timing function
3. Electricity indicator
4. Charging instruction
5. Infrared remote control
6. Intelligent power reduction
7. Hongsong die casting-banana fan model
Company Profile
Certifications
Packing&Shipping
Why Choose Us
We have our own R&D team, All of our electronic circuit boards such as LED driver & driverless, stepless dimming lighting and sound controller, RGB driver, solar controller, PIR sensor ,microwave sensor, and other smart products are designed by our engineers and manufactured in our own factory. So we can control the quality and prices of these products and can change any parameter to customize these products by your requirements. Of course, we have the most competitive prices in the market.
FAQ
Q1: What are your main business?
A1: We are led driver and driverless manufacturer ,we can supply the PCBA ,also can supply SKD for led tube lights, led flood lights, Led solar street lights etc.
Q2: How about your quality?
A2: Our company is manufacturer , using top quality material to make sure each light is stable quality,enough brightness and good performance. Every product has passed aging test well before delivering it to clients.
Q3: How long is the warranty time?
A3: We supply 2-5 years warranty. Once you find quality problem from our company during warranty period, please provide us pictures or videos to confirm, if it's our quality problem, we will send you replacement, you don't undertake any shipping cost.
Q4: Can you send me samples?
A4: Yes, we can, but you must pay the courier fee. we will refund it to you if you have become our client in the future.
We are looking for distributors and companies from all over the world for cooperation, if any questions or interest, please don't hesitate to contact us now!
