Сверхкритическая жидкость для экстракции оливкового масла дистилляции 48 л (24Lx2)
- Категория: Extractor >>>
- Поставщик: Careddi,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 98770.24 $* | 103709.33 $* |
| Aug-18-2025 | 97940.37 $* | 102837.66 $* |
| Jul-18-2025 | 82170.30 $* | 86279.90 $* |
| Jun-18-2025 | 96280.27 $* | 101094.79 $* |
| May-18-2025 | 83830.39 $* | 88022.96 $* |
| Apr-18-2025 | 94620.8 $* | 99351.92 $* |
| Mar-18-2025 | 93790.14 $* | 98480.57 $* |
| Feb-18-2025 | 92960.47 $* | 97608.78 $* |
| Jan-18-2025 | 92130.7 $* | 96737.80 $* |
Характеристики
Product Description
Careddi supercritical CO2 extraction system is used under high pressure and suitable temperature suitable to extract valuable content from material (solid or liquid), it is to change the pressure and temperature conditions of the separator tanks to let the dissolved substances separated out to achieve the purpose of separation. This technology could be used to make extraction and purification on biological products, foodstuff and medicines, etc.
Product Name | Supercritical CO2 Extraction Machine |
Usage | Plants/flowers extraction |
Material | 304 Stainless steel |
Color | Sliver, accept customized |
Certification | ISO CE ASME |
Capacity | 48L |
Model no. | SCFE48L |
Characteristics of Careddi Supercritical co2 extractor:
1. Low critical temperature, suitable for extraction and purification of heat sensitive compound.
2. Being capable to provide insert environment to avoid oxidation of products and affection of effective content of extracts.
3. Fast extraction speed, no toxicity, non-flammable, safe application and no pollution upon environment.
2. Being capable to provide insert environment to avoid oxidation of products and affection of effective content of extracts.
3. Fast extraction speed, no toxicity, non-flammable, safe application and no pollution upon environment.
4. No residue of solvent, no nitrate and ions of heavy metal.
Application:
Range of Application | Type of Application |
Pharmaceutical Industry | Extraction of effective contents of Chinese herbs, concentration, refinement and precipitation of raw material drug, separation and refinement of fatty mixtures. |
Foodstuff Industry | Extraction of hops, caffeine removal from coffee berry, extraction of plant. |
Cosmetics and Perfumery Industry | Separation and refinement of natural and synthetic perfumeries, dealkalization of tobacco, extraction of raw material cosmetics. |
Chemical Industry | Separation of hydrocarbon, refinement of organic synthetic raw material, separation of azeotrope, retrieval of raw materials of reaction, dehydration of water soluble powder of organic solution, water oxidation. |
Others | Superconducting, semiconductor, ceramics, oil washing of petroleum core, enzyme catalytic reaction, preparation of materials, superfine granules, extraction of complex compound, supercritical dyeing technique, supercritical reaction, supercritical coating technique (pharmacy-making). |
Supercritical CO2 Extraction Device-48L technical parameters:
SIGN | CONFIGURATION | Qty | REMARK |
1 | Extraction Tank | 2 | Volume:24Lx2 Max working Pressure:40MPa |
2 | Separation Tank | 2 | Volume:20Lx1+10Lx1 Max working Pressure：30MPa |
3 | CO2 high-pressure pump | 1 | 600L/Hour, 40MPa, pumps head with cooling system |
4 | Co-solvent pump | 1 | 0.25-20L/H,40MPa (Mechanical adjustable) |
5 | Chiller | 1 | Temperature range：-5℃～+5℃ |
6 | Heating Exchange System | 1 | Max working Pressure：40MPa |
7 | Purification System | 1 | Max working Pressure：40MPa |
8 | CO2 Storage Tank | 1 | Max working Pressure：16MPa |
9 | Flowrate Meter | 1 | Model:Metal tube float (10-100L/H) |
10 | Temperature Control System | 1 | Temperature Range: Room temperature~75℃ |
11 | Safety Devices | Pressure gauge at high pressure pump outlet, overpressure protection The extractor, separator, evaporator, dry purifier and mixer have safety valve to keep safe of system. | |
12 | User-supplied | Power:3 phase CO2: Food grade≥99.5%, single bottle net weight ≥22Kg Food grade alcohol ≥99.5% Installation dimension: 2700×2500×1600mm |
