Инвертор 12 В 220 в 2000 Вт 3000 6000 Пиковая чистая Синусоидальная волна 24 110 солнечный инвертор для домашней системы солнечной энергии с зарядным устройством
- Категория: Inverters & Converters >>>
- Поставщик: Foshan,Top,One,Power,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.52 $* | 0.91 $* |
| Aug-16-2025 | 0.10 $* | 0.3 $* |
| Jul-16-2025 | 0.87 $* | 0.65 $* |
| Jun-16-2025 | 0.1 $* | 0.74 $* |
| May-16-2025 | 0.69 $* | 0.33 $* |
| Apr-16-2025 | 0.65 $* | 0.58 $* |
| Mar-16-2025 | 0.86 $* | 0.76 $* |
| Feb-16-2025 | 0.74 $* | 0.55 $* |
| Jan-16-2025 | 0.14 $* | 0.33 $* |
Характеристики
FTS Series solar inverter off grid solar system with mppt charge controller inverter mppt solar inverter hybrid
off grid low frequency Pure sine wave HYBRID solar inverter,
it range from 1kw ~7kw,
transfer efficiency >90%, switch time <4ms, inbuilt
Built in 30A 50A MPPT solar charge controller/ 35A AC charger / AVR stablizer / intelligent cooling system,
using latest toroidal tranformer, triple surge power,
64-Bits DSP control chipset
transfer efficiency >90%, switch time <4ms, inbuilt
Built in 30A 50A MPPT solar charge controller/ 35A AC charger / AVR stablizer / intelligent cooling system,
using latest toroidal tranformer, triple surge power,
64-Bits DSP control chipset
MODEL | FTS-102 | FTS-202 | FTS-302 | FTS-402 | FTS-502 | FTS-602 | ||||||
RATED POWER | 1KW | 2KW | 3KW | 4KW | 5KW | 6KW | ||||||
SURGE POWER | 3KW | 6KW | 9KW | 12KW | 15KW | 18KW | ||||||
INPUT | ||||||||||||
VOLTAGE | 220VAC | |||||||||||
SELECTABLE VOLTAGE RANGE | 145-265VAC | 170-265VAC | ||||||||||
FREQUENCY RANGE | 50HZ/60HZ±5HZ | |||||||||||
OUTPUT | ||||||||||||
AC VOLTAGE REGULATION(BATT. MODE) | (DC BATT.MODE)220VAC±3% | |||||||||||
TANSFER TIME | ≤5ms | |||||||||||
WAVE FORM | PURE SINE WAVE | |||||||||||
BATTERY | ||||||||||||
BATTERY VOLTAGE | 12V/24V | 24V/48V | ||||||||||
FLOATING CHARGE VOLTAGE | 13.8V(12V)/27.6V(24V)/55.2V(48V) | |||||||||||
OVERCHARGE PROTECTION | 17V(12V)/34V(24V)/68V(48V) | |||||||||||
SOLAR CHARGE & AC CHARGER | ||||||||||||
MAXIMUM PV ARRAY OPEN CIRCUIT VOLTAGE | 150VDC | |||||||||||
MAXIMUM PV ARRAY POWER | 420W(12V)/840W(24V) | 1400W(12V)/2800W(48V) | ||||||||||
STANDBY POWER COMSUMPTION | 15W | |||||||||||
MAXIMUM AC CHARGE CURRENT | 35A | |||||||||||
MAXIMUM SOLAR CHARGE CURRENT | 30/50A(OPTIONAL) | 30-60A(OPTIONAL) | ||||||||||
MAXIMUM CHARGING CURRENT | 85A | 95A | ||||||||||
PHYSICAL | ||||||||||||
DIMENSION,D*W*H(MM) | 530*335*250MM | 740*335*275MM | ||||||||||
G.W. | 18.8 | 24.8 | 28.3 | 34.9 | 36.9 | 38.9 | ||||||
ENVIRONMENT | ||||||||||||
HUMIDITY | 0~95%（NO CONDESNSATION) | |||||||||||
OPERATING TEMPERATURE | 0~60℃ | |||||||||||
STORAGE TEMPERATURE | 0~60℃ | |||||||||||
*PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT FURTHER NOTICE | ||||||||||||
FAQ
Q1: Does your company also provide other solar products except Pure Sine Wave Inverter?
A1: Yes, we also provide other solar products, like MPPT Solar Controller, poly solar panel, off grid solar inverter, on grid
inverter, battery, portable solar system, solar charger and other accesories
related to the solar power system.
Q2: How to choose a right inverter?
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
Q3: How about the delivery time?
A3: 5 days for sample; 7-15 days for bulk order.
Q4: What is the warranty of inverter?
A4: 2 year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
A1: Yes, we also provide other solar products, like MPPT Solar Controller, poly solar panel, off grid solar inverter, on grid
inverter, battery, portable solar system, solar charger and other accesories
related to the solar power system.
Q2: How to choose a right inverter?
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
Q3: How about the delivery time?
A3: 5 days for sample; 7-15 days for bulk order.
Q4: What is the warranty of inverter?
A4: 2 year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
