Characteristic

* Rated U and I: 3×220/380V,3×380V, 3×57.7/100V,3×100V

*Display: LCD dispaly

* Communication:  RS485(Modbus-RTU)

* K : 4DI/2DO

* T : 4 Channels temperature measure

* L : 1 Channel residual current measure

* LR : Lora wireless communication

* 2G : 2G wireless communication

* NB : NB -IOT wireless communication

Function

Accuracy Active energy: Class 0.5S Reactive energy: Class 2  Frequency 50/60HZ(Optional),range: 45~65HZ Pulse output Active pulse output and Reactive pulse output(or Clock pulse output) Consumption <10VA (Single phase)
	Dimension(L*W*H) 72*87.8*71.5mm   Starting current 0.4%Ib

Parameter
