60 тонн пересеченной местности кран синовай 4X4 гидравлический автокран на

60 тонн пересеченной местности кран синовай 4X4 гидравлический автокран на

Категория: Автокраны >>>
Поставщик: Sinoway,Industrial,(Shanghai),Co.,Ltd.

Цена:429 000,00 $ - 430 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	510510.76 $*	536036.14 $*
Aug-16-2025	506220.94 $*	531531.0 $*
Jul-16-2025	424710.43 $*	445946.29 $*
Jun-16-2025	497640.44 $*	522522.28 $*
May-16-2025	433290.57 $*	454955.63 $*
Apr-16-2025	489060.2 $*	513513.69 $*
Mar-16-2025	484770.85 $*	509009.61 $*
Feb-16-2025	480480.60 $*	504504.54 $*
Jan-16-2025	476190.73 $*	500000.61 $*

Характеристики

Products Description

Equipped with powerful Cummins engine, 46m main boom, 17.5m auxiliary jib, under the same boundary conditions, the comprehensive lifting performance is the strongest.
Maneuvering and Flexible, Quick and Efficient
The max speed reaches 35km/h and the max gradeability is 65% and the min. turning radius is 7.5m. All these three factors make it flexible.
The product is equipped with great power system, specialized cross-country pattern tire and skid-resisting differential locking gear. All these three factors make it drive over all kinds of road easily.
Safe and Reliable,Easy to Handle
The SWORC800 rough terrain crane is equipped with lifting protection control system in case of overload, over-retracting and over-stretching as well as exclusive technology in this field like rear axle-wheel automatic return-control system and safety-driving automatic protection system. All these elevate its safety performance largely.
The SWORC800 is equipped with top features in this field, professional matching upgrading and systematic evaluation test. And it has passed test like driving 4,000km and 10,000 times hanging. Both ensure its reliability.
Comfortable to Handle, Convenient to Operate
This 4x4 off road crane is equipped with full hydro-steering control system and automatic-manual gear box, which make it easy to handle. And it is equipped with turnover handling room, which presents a border view and makes it more comfortable to operate.
The product is equipped with humanized climb ladder, maintenance access and control layout. And it is equipped with professional man-machine engineering simulation analysis; exquisite man-machine interface and stand-alone fault diagnose function. It is comfortable to handle and convenient to operate.

Product Paramenters

Engine
Model	Cummins
Type	Six-cylinder,water-cooled electronic injection
Rated power	209KW
Rated speed	2100rpm
Crane Parameters
Max. total rated lifting load	80t
Boom	11.9~46m
Fully extended boom+jib	63.5m(two-section,angle 0°,30°)
Base boom	11.32m
Main winch	125m/min
Auxiliary winch	125m/min
Boom angle	-2°~80°
Boom elevating time	110s
Boom extending time	155s
Slewing speed	2r/min
Turning radius at swing table tail	4625mm
Hydraulic System
Lifting device	Axial piston hydraulic motor
Slewing device	Axial piston hydraulic motor
Hydraulic ram capacity	700L
Equipments and Structure
Boom profile	Five-section boom of octagon cross section
Jib profile	Two-section truss (inclination 0°,30°)
Boom extending device	Two-section telescopic cylinder and rope
Boom elevating device	Rear-mounted single cylinder elevation
Lifting device	Isolated main and auxiliary lifting devices,plantary reducer driven by hydraulic motor
Slewing device	Three-row roller slewing ring
Outrigger device
Type	H-shaped hydraulic outrigger with an option of both hand and electric control
Outrigger span	7800x7600mm (longitudinal+lateral)
Steel wire rope of main winch	Φ20~220m
Steel wire rope of auxiliary winch	Φ18~190m
Performance Specification
Max.speed	36km/h
Grade ability	60%
Four wheel steering radius	7.0m
Min.turning radius of jib nose	10.5m
Undercarriage and Structure
Drive type	4×4/4×2
Steering mode	Independent front axle, steering,small truning radius,crab walk and independent rear axle steering
Suspension	Rigid front axle,swing rear axle,hydraulic locking cylinder,electric control
Service brake	Hydraulic dual circle,disc brake
Parking brake	Mechanical disc brake,hydraulic release
Fuel tank capacity	320L
Dimension and weight
Overall length	14050mm
Overall width	3400mm
Overall height	3990mm
Wheel base	4650mm
Front tread	2520mm
Rear tread	2520mm
Overall weight	58000kg
Front axle weight	30350kg
Raer axle weight	27650kg
