Шланг тормоза авто
Резиновый плетеный автомобильный шланг sae j1401 1/8 дюйма hl для

Резиновый плетеный автомобильный шланг sae j1401 1/8 дюйма hl для

Категория: Шланг тормоза авто >>>
Поставщик: Hebei,Orient,Rubber,&,Plastic,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.15 $*	0.44 $*
Aug-16-2025	0.48 $*	0.38 $*
Jul-16-2025	0.45 $*	0.38 $*
Jun-16-2025	0.13 $*	0.97 $*
May-16-2025	0.75 $*	0.71 $*
Apr-16-2025	0.64 $*	0.94 $*
Mar-16-2025	0.81 $*	0.27 $*
Feb-16-2025	0.82 $*	0.7 $*
Jan-16-2025	0.81 $*	0.52 $*

Характеристики

product description

air-brake-hose hydraulic-brake-hose

SAE J1401 DOT 1/8 HL Hydraulic Brake Hose With Fittings

Applications

Designed for pressure transmission for auto, truck and trailer hydraulic pressure brake systems.Truck and trailer manufacturers,aftermarket packagers and wholesalers use this hose. It is certified to meet SAEJ1401 requirements.
Temperature range : -40~+100°C
Construction
External layer:CR/EPDM
Reinforcement :PET
Middle layer :NBR
Reinforcement :PET
Internal layer:EPDM

Specification

Item Code	I.D	O.D	Wall Thickness	Wall Diff	Expansion Max. ml/m		Min.Brust Pressure
Item Code	mm	mm	mm	mm	6.9MPa	10.3MPa	MPa
1	3.2	10.5±0.2	3.65	≤0.25	<1.08	<1.38	>80
2	4.8	13±0.3	4.35	≤0.3	<1.81	<2.36	>60
3	6.3	15±0.3	3.75	≤0.3	<2.69	<3.84	>50

Product show:

Packing

Packing:After finishing the hydraulic brake hose production, we will pack the hose.
In general, the packing will use woven bag and plastic film.
Special packing is available according to customers' requirements.

packing
