24D станок для волочения медной проволоки от
- Категория: Wire Drawing Machines >>>
- Поставщик: Shanghai,Swan,International,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.27 $* | 0.60 $* |
| Aug-16-2025 | 0.95 $* | 0.3 $* |
| Jul-16-2025 | 0.96 $* | 0.12 $* |
| Jun-16-2025 | 0.34 $* | 0.14 $* |
| May-16-2025 | 0.28 $* | 0.57 $* |
| Apr-16-2025 | 0.16 $* | 0.64 $* |
| Mar-16-2025 | 0.88 $* | 0.91 $* |
| Feb-16-2025 | 0.10 $* | 0.38 $* |
| Jan-16-2025 | 0.32 $* | 0.3 $* |
Характеристики
Product Description
24D FINE WIRE DRAWING MACHINE | ||
Machine Model | 24D | |
Power Control | Dual Inverter Control | |
Inlet Dia. (mm) | Φ0.5-Φ1.2mm | |
Outlet Dia. (mm) | Φ0.10-Φ0.52mm | |
Max Die No. | 24 | |
Max Line Speed (m/min) | 2000m/min | |
Area Reduction Ratio of Machine | 13% | |
Area Reduction Ratio of Final Capstan | 8% | |
Main Motor Power | 15kw | |
Take up Motor Power | 4kw | |
Max capstan diameter | Φ194mm | |
Fix speed capstan diameter | Φ159mm | |
Take Up Bobbin Size | D300 Bobbin | |
Dimension | 2200 x 1600 x 1900mm (L x W x H) | |
Product Description
