Двухкомнатная вакуумная упаковочная машина YF двухкамерная для риса арахиса чая
- Категория: Вакуумные упаковочные машины >>>
- Поставщик: Anhui,Yifei,Intelligent,Packaging,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 833.86 $* | 875.24 $* |
| Aug-16-2025 | 826.77 $* | 867.22 $* |
| Jul-16-2025 | 693.36 $* | 728.73 $* |
| Jun-16-2025 | 812.40 $* | 853.66 $* |
| May-16-2025 | 707.24 $* | 742.95 $* |
| Apr-16-2025 | 798.63 $* | 838.4 $* |
| Mar-16-2025 | 791.57 $* | 831.61 $* |
| Feb-16-2025 | 784.5 $* | 823.83 $* |
| Jan-16-2025 | 777.18 $* | 816.5 $* |
Характеристики
Product Description
Features
1. It is featured by automatic processing of vacuuming, sealing, printing, cooling;
2. Digital vacuum degree display panel;
3. Vacuum degree and seal temperature can be adjusted;
4. It is specially designed with arch design;
5. Wearable silicon sealing wire with long-time using;
6. High vacuum degree with perfect quality.
2. Digital vacuum degree display panel;
3. Vacuum degree and seal temperature can be adjusted;
4. It is specially designed with arch design;
5. Wearable silicon sealing wire with long-time using;
6. High vacuum degree with perfect quality.
Model | DZ-400-2S | DZ-500-2S | DZ-6002S` |
Power | 220/380V 50HZ | 380V/50HZ | 380V/50HZ |
Voltage | 0.8W | 1.6KW | 2.2KW |
Effective sealing size | 400*10MM | 500*10MM | 600*10MM |
Vacuum chamber size | 520*550*90MM | 620*560*90MM | 720*600*100MM |
Hot air strip length | 400MM | 415MM | 470MM |
Vacuum pump exhaust | 20m³/H | 40m³/H | 60m³/H |
Shape size | 1030*630*850MM | 1220*660*900MM | 1425*720*950MM |
Net weight | 80KG | 170KG | 200KG |
Operation steps of vacuum packaging machine
1. Turn on the power supply: switch the power supply to select the switch according to the need, that is, the power indicator light is on. The power supply selection switch points to vacuum sealing and vacuum charging to vacuum sealing.
2. Place the plastic bags containing articles in the vacuum chamber. The mouth of the bag is neatly placed on the heat seal (ifinflatable packing, at least one nozzle should be inserted into the mouth of the bag).
3. Press down the cover of the machine and light the exhaust (vacuum) indicator on the panel.When the vacuum pump starts pumping, the cover is automatically sucked. The vacuum knob can adjust the vacuum degree according to
the packaging requirements. When adjusting, the visual scale is from low to high, and the range is small.
4. When the exhaust reaches the set time (i.e. the required vacuum), the exhaust end, the exhaust indicator lights out, and the inflatable indicator lights up to indicate the beginning of inflatability. The inflatable knob can adjust the inflatable time
(i.e. the amount of inflatable), the method is the same as the above. If there is no need to inflate, set the power switch to the vacuum position, the program automatically enters the vacuum packaging, and the inflatable indicator lights out.
5. When the exhaust or inflation is completed, the indicator lights will be extinguished, and the heat seal indicator lights will be on, i.e. enter the sealing procedure. The panel is equipped with heat seal time and temperature adjustment knobs to adapt to different thickness materials. When adjusting time and temperature, the rotation range will be small to prevent the sudden increase of the heat seal temperature.
6. When the heat sealing time is set, the heat sealing indicator lights will go out and the heat sealing will be finished. That
is, the vacuum chamber enters the atmosphere through the solenoid valve until the cover is lifted automatically, and the vacuum filling packaging process will be completed. The next packaging cycle will be prepared.
2. Place the plastic bags containing articles in the vacuum chamber. The mouth of the bag is neatly placed on the heat seal (ifinflatable packing, at least one nozzle should be inserted into the mouth of the bag).
3. Press down the cover of the machine and light the exhaust (vacuum) indicator on the panel.When the vacuum pump starts pumping, the cover is automatically sucked. The vacuum knob can adjust the vacuum degree according to
the packaging requirements. When adjusting, the visual scale is from low to high, and the range is small.
4. When the exhaust reaches the set time (i.e. the required vacuum), the exhaust end, the exhaust indicator lights out, and the inflatable indicator lights up to indicate the beginning of inflatability. The inflatable knob can adjust the inflatable time
(i.e. the amount of inflatable), the method is the same as the above. If there is no need to inflate, set the power switch to the vacuum position, the program automatically enters the vacuum packaging, and the inflatable indicator lights out.
5. When the exhaust or inflation is completed, the indicator lights will be extinguished, and the heat seal indicator lights will be on, i.e. enter the sealing procedure. The panel is equipped with heat seal time and temperature adjustment knobs to adapt to different thickness materials. When adjusting time and temperature, the rotation range will be small to prevent the sudden increase of the heat seal temperature.
6. When the heat sealing time is set, the heat sealing indicator lights will go out and the heat sealing will be finished. That
is, the vacuum chamber enters the atmosphere through the solenoid valve until the cover is lifted automatically, and the vacuum filling packaging process will be completed. The next packaging cycle will be prepared.
Production display
Certifications
Our Advantages
Our Advantages
*Best product and factory price
*On-time delivery and the shortest delivery time.
*OEM and customized service.
*User manuals will go with relative machines.
*1-Year warranty
If our product cannot function properly within 12 months,
we'll offer spare parts for free ; and you need to pay for the delivery.
*Best product and factory price
*On-time delivery and the shortest delivery time.
*OEM and customized service.
*User manuals will go with relative machines.
*1-Year warranty
If our product cannot function properly within 12 months,
we'll offer spare parts for free ; and you need to pay for the delivery.
Why Choose Us
1) Warranty Time: 1 year, within this period we offer spare part replacement freely if there are any Non-artificial damage on them.
2) Quality: Quality of products will be strictly checked and every machine will be test to ensure it can works well before packaging.
3) Technical services: We will keep contacting with our customers all the time after selling out the machine. Please contact us without hesitation if you need any help on machines.
4) File Services: We offer instruction manual and video to teach you how to using and testing machine.
5) Accessories: with competitive price when you need it.
In addition,if you have any idea or special requirement for plastic sealer machine details, we will do our best to solve for you. We believe our sincerity and specialty, could bring good user experience to customers. |
FAQ
Q: Are you trading company or manufacturer ?
A:Yes, We are factory, all machine is made by ourself and we can provide customize service according to your requirement.
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 3-7 days if the goods are not in stock, it is according to quantity.
Q:What about your warranty?
A:Our warranty is 1 year, all machine part can be replaced for free within 1year if broken(not including man made).
Q: What is your terms of payment?
A: Payment<=5000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: Is there any installation direction after we received the machine?
A: Yes, we have a professional technical team and warm after service. We will solve any problem you meet during the installation and packing production in time.
Q: Is there any ensurance to guarantee my order from your company?
A: We are an onsite check factory from Alibaba, and the quality, delivery time, your payment are all ensured by Alibaba trade assurance.
A:Yes, We are factory, all machine is made by ourself and we can provide customize service according to your requirement.
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 3-7 days if the goods are not in stock, it is according to quantity.
Q:What about your warranty?
A:Our warranty is 1 year, all machine part can be replaced for free within 1year if broken(not including man made).
Q: What is your terms of payment?
A: Payment<=5000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: Is there any installation direction after we received the machine?
A: Yes, we have a professional technical team and warm after service. We will solve any problem you meet during the installation and packing production in time.
Q: Is there any ensurance to guarantee my order from your company?
A: We are an onsite check factory from Alibaba, and the quality, delivery time, your payment are all ensured by Alibaba trade assurance.
Product packaging
Company Profile
Anhui Yifei Intelligent Packaging Machinery Co., Ltd. is a collection of R&D, design, production, installation, commissioning and technical services, relying on technology to provide customers with packaging equipment solutions.
The company's main products are: granular packaging machine, powder packaging machine, sauce liquid packaging machine, tea packaging machine, rotating bag packaging machine, horizontal packaging machine, multi-row packaging machine, pillow packaging machine, vacuum packaging machine, automatic shrink film sealing machine, open box machine, packing machine, packing machine, palletizing machine, winding machine,spraying machine, filling machine, sealing machine, labeling machine, etc. packaging machinery and supporting production lines.
Our products are widely used in food, medicine, chemical industry, hardware, pesticides, logistics and other industries. After several years of development and growth, the company has established a sound sales network and service network, products sold well throughout the country, and exported to Europe, America, Southeast Asia and other countries all over the world
Our products are widely used in food, medicine, chemical industry, hardware, pesticides, logistics and other industries. After several years of development and growth, the company has established a sound sales network and service network, products sold well throughout the country, and exported to Europe, America, Southeast Asia and other countries all over the world
Warmly welcome You to Y-F Packaging Machinery for inspection and business negotiation.
