Модуль LoRa 915 МГц предоплаченный измеритель электроэнергии
- Категория: Energy Meters >>>
- Поставщик: Shanghai,Ivy-Metering,Electronic,Technology,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.55 $* | 0.98 $* |
| Aug-19-2025 | 0.55 $* | 0.34 $* |
| Jul-19-2025 | 0.84 $* | 0.11 $* |
| Jun-19-2025 | 0.48 $* | 0.45 $* |
| May-19-2025 | 0.6 $* | 0.99 $* |
| Apr-19-2025 | 0.6 $* | 0.82 $* |
| Mar-19-2025 | 0.87 $* | 0.81 $* |
| Feb-19-2025 | 0.44 $* | 0.99 $* |
| Jan-19-2025 | 0.75 $* | 0.63 $* |
Характеристики
Type | 1 Phase 2 Wires Din Rail Meter | |
Reference Voltage | 220V | |
Current | 5(60)A | |
Accuracy Class | 1.0 | |
Communication | Lora Wan,868MHz | |
Rated Frequency | 50Hz | |
Standard | IEC62052-11/IEC62053-21, IEC62055-41/IEC62056-21 | |
Impulse Constant | 1600imp/kWh | |
Display | LCD 5+1 | |
Power Consumption | <2W / <10VA | |
Temperature Range | -20～70℃ | |
Annual Average Humidity value | 75% | |
Maximal Humidity Value | <95% | |
Case & Base | PC+ABS | |
Nameplate | PVC | |
Dimension | 90*72*36mm | |
Weight | 0.10Kg | |
Impulse Light | 80ms | |
Relay | Built-in 80A Relay |
Cautions:
1.About AC/DC Energy Meter
(1) AC or DC- Generally speaking alternating current or direct current shall be the first factor.
(2) We also have DC meter when you need to measure the Direct Current.
2.About Function
(1) As the content is limited, all functions mentioned above are the main functions
(2) Other functions such as TOU, load control, friendly hours,RTC, plz refer to the technical specification or
(1) AC or DC- Generally speaking alternating current or direct current shall be the first factor.
(2) We also have DC meter when you need to measure the Direct Current.
2.About Function
(1) As the content is limited, all functions mentioned above are the main functions
(2) Other functions such as TOU, load control, friendly hours,RTC, plz refer to the technical specification or
contact with our sales team.
3.About Application
(1) The applications only for examples, for the pratical situation the energy meter can also be used for
3.About Application
(1) The applications only for examples, for the pratical situation the energy meter can also be used for
other applications.
(2) Welcome to inquiry if you are not sure about the functions or application, we have free technical support
(2) Welcome to inquiry if you are not sure about the functions or application, we have free technical support
