Хит продаж, высокопрочный насос для бетонных насосов
US $4800-$5300
Лидер продаж мини-стационарный легкий гидравлический цементный смеситель с дизельным двигателем бетононасос поролоновым прицепом из
- Категория: Concrete Pumps >>>
- Поставщик: Shandong,Jinrui,Heavy,Industry,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 21777.69 $* | 22866.21 $* |
| Aug-16-2025 | 21594.44 $* | 22674.67 $* |
| Jul-16-2025 | 18117.33 $* | 19023.29 $* |
| Jun-16-2025 | 21228.20 $* | 22289.98 $* |
| May-16-2025 | 18483.91 $* | 19407.63 $* |
| Apr-16-2025 | 20862.99 $* | 21905.49 $* |
| Mar-16-2025 | 20679.68 $* | 21713.58 $* |
| Feb-16-2025 | 20496.85 $* | 21521.54 $* |
| Jan-16-2025 | 20313.42 $* | 21329.88 $* |
Характеристики
Product Description
Feature
Using the duplex hydraulic pump system,have excellent characteristics of with small size, small operating space, owing the high quantities of concrete, mature and stable performance
Product Application
♦Products are suitable for all kinds of 2 to 12 floors of small and medium-sized housing construction,as well as a variety of mine, water conservancy and hydropower engineering, highway,rail tunnel, slope geological disaster control engineering, etc.
♦ High quality concrete mixer and pump equipped with high efficiency concrete pumping system.♦ Hydraulic double-cylinder piston system, more stable flow, more uniform and
stable spraying.
♦ Dual-piston alternately working, manual and automatic hydraulic synchronous lubrication
system, longer mortar piston life.
♦ Further optimized pumping flow path to reduce the pumping resistance and the probability
of tube block. Mortar stop pressure relief valve, pumping cleaning ball washing, more
secure and faster cleaning operation.
♦ Advanced hydraulic system.
SPECIFICATIONS FOR JZC350-H | ||||||
JZC350-H | Brand name | Jinruifu | ||||
Charging Capacity | L | 560 | ||||
Discharging capacity | L | 350 | ||||
Charging Way | / | Hydraulic | ||||
Speed of mixing drum | r/min | 17 | ||||
Output | m3/h | 11-13 | ||||
Max aggregate diameter | mm | 60 | ||||
Item(JBT30-II) | Unit | JBT30-II | |
Max.Theo. Output | m^3/h | 30 | |
Distribution valve | S valve | ||
Hopper capacity x Filling height | L x mm | 500*1200 | |
Pumping motor power | kw | 55 | |
Winding motor power | kw | 4 | |
Hydraulic oil type | Open loop | ||
Rated speed | Rpm | 1480 | |
Oil tank cubage | L | 170 | |
Weight | kg | 3500 | |
Concrete delievery pressure | Mpa | 9 | |
Concrete cylinder dia. x stroke | mm | 200*1200 | |
Discharging mouth diameter | mm | 150 | |
Mixer power | kw | 3*2 | |
Water pump power | w | 550 | |
Max. Allowed aggregate diameter | mm | Pebble:40 Crush stone:30 | |
Voltage/Frequency | v | 380 | |
Dimensions(L*W*H) | mm | 4300*2060*3680 | |
Our advantage
Reduce the labor intensity of workers.
The operation is simple.
Less vulnerable parts, save traditional components such as wire rope, limiter, brake pad.
Simple maintenance and low cost.
More safety, the aggregate hopper not easy to fall off.
The hopper is not easily deformed and has a long service life.
Manganese steel cylinder body, wear-resisting.
National standard motor.
More practical.
Suitable for places without electricity.
Real Manufacture and OEM.
Detailed Images
Hydraulic oil cylinder
1.Save wire rope, limiter, brake pad, less vulnerable parts,
2.Keep the hopper long service life without deformation
3.Low noise.
4.More safety, the aggregate hopper not easy to fall off.
Directional control valve
1.rise and fall the hopper.
2.Reduce the labor intensity of workers.
3.Simple maintenance and low cost.
Electric control system
1.Schneider brand electric appliances.
2.Easy operation.
3.Reduce the labor intensity of workers.
Ring gear transmission
1.Stable transmission and not slippery.
2.Roller supports the drum to turn.
Pump
1. better stability
The pump adopts hydraulic pump and import group valve to better stability and longer service life.
2. strong transfer capability
With 200-230mm transfer pipe, the pump can transfer more concrete and deal with aggregate diameter in 40mm.
3. high efficiency
The dump is more automatable, and can save labor. The hydraulic outrigger we adopted in the product can save configuration time
than3times.
The pump adopts hydraulic pump and import group valve to better stability and longer service life.
2. strong transfer capability
With 200-230mm transfer pipe, the pump can transfer more concrete and deal with aggregate diameter in 40mm.
3. high efficiency
The dump is more automatable, and can save labor. The hydraulic outrigger we adopted in the product can save configuration time
than3times.
The advantages of the special pump for the construction of the column:
(1) fully mechanized operation, it is the hundredfold of man-made concrete, shortened the construction period.
(2) the pump is concreted with good continuity, high efficiency and economical labor cost.
(3) this pump is small in size, convenient in construction and simple in operation, which can be poured directly into the floor
and greatly reduces the intensity of labor.
(4) this pump is equipped with high quality, light weight, easy to move, easy to maintain, and low maintenance cost.
(5) the power of this pump is very low, considering the convenient problem of using electricity at construct
(1) fully mechanized operation, it is the hundredfold of man-made concrete, shortened the construction period.
(2) the pump is concreted with good continuity, high efficiency and economical labor cost.
(3) this pump is small in size, convenient in construction and simple in operation, which can be poured directly into the floor
and greatly reduces the intensity of labor.
(4) this pump is equipped with high quality, light weight, easy to move, easy to maintain, and low maintenance cost.
(5) the power of this pump is very low, considering the convenient problem of using electricity at construct
Our Service
Pre-Sales and After-Sales Service
Inquiry and consulting support.
Sample testing support.
View our Factory.
Sample testing support.
View our Factory.
Training how to instal the machine, training how to use the machine.
Engineers available to service machinery overseas.
Engineers available to service machinery overseas.
Packing & Delivery
Our Company
Shandong Jinrui Heavy Industry Machinery Co.,Ltd
Shandong jinrui hevay industry machinery CO.,LTD was established in 2001, which is located in Anqiu,Shandong, China. It is only 160 kilometers way from Qingdao port, which is biggest prot in north of China. We specialized in construction machinery,which is including concrete mixers(including JZ series counter- rotary with double cones, JS series compulsory mixer with double lying shafts, LSY cement spiral conveyor, cement silo, PLD concrete proportioning MC series and concrete plant ETC).The concrete mixers can be widely used in all kind of prefabrications, roads, bridges, ports and civil constructions and so on. The can mix stable soil concrete, plastic concrete, fluidity concrete, light aggregate concrete and mortars.
Now all the constuction MC have passed state quality standard GB9142-2000, and our company have passed international quality management ISO9001-2000.
We belive "customers foremost, credit first" and insist on providing satisfaction to the customers, we have created strong sales network all over the country and overseas covering east asia, southeast asia and africa.
We are the manufacture.
Near to Qingdao port.
OEM acceptable.
16 years of production experience and 6 years of exporting experience.
Competitive price with high quality
JINRUIFU is China top 10 famous brand
Main production:JZC series mixer, JS series mixer, concrete mixing plants and mobile concrete batching plant.
We have created strong sales network all over the country and overseas covering East Asia,South Asia and Africa.
We are the manufacture.
Near to Qingdao port.
OEM acceptable.
16 years of production experience and 6 years of exporting experience.
Competitive price with high quality
JINRUIFU is China top 10 famous brand
Main production:JZC series mixer, JS series mixer, concrete mixing plants and mobile concrete batching plant.
We have created strong sales network all over the country and overseas covering East Asia,South Asia and Africa.
Exibition Picture and Customer Visit
Jinruifu Machine,be part of your success
FAQ
Q: How about the quality of your products?
A: We are factory with more than 16 years of construction machinery manufacturing experience. All of our machines are manufactured strictly according to the national and international standards, and we take a test on each equipment before delivery. You can also use Trade Assurance by Alibaba for product quality protection, on-time shipment protection and payment protection.
Q: How about the price?
A: We are manufactory, not dealer, so we can give you a lower price than those trade companies can.
Q: Do you provide after-sale service?
A: Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and
thoroughly solve your problems.
Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passports.
A: We are factory with more than 16 years of construction machinery manufacturing experience. All of our machines are manufactured strictly according to the national and international standards, and we take a test on each equipment before delivery. You can also use Trade Assurance by Alibaba for product quality protection, on-time shipment protection and payment protection.
Q: How about the price?
A: We are manufactory, not dealer, so we can give you a lower price than those trade companies can.
Q: Do you provide after-sale service?
A: Yes. The warranty period of our machines is one year, and we have a professional after-sale service team to promptly and
thoroughly solve your problems.
Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passports.
