SUNKKO 797DH многозарядное зарядное функцией высокой мощности для точечной сварки мульти ИМПУЛЬСНЫЙ аппарат
- Категория: Spot Welders >>>
- Поставщик: Shenzhen,Fundar,Technology,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 278.7 $* | 284.83 $* |
| Jul-16-2025 | 226.88 $* | 231.41 $* |
| Jun-16-2025 | 274.19 $* | 279.22 $* |
| May-16-2025 | 272.23 $* | 277.71 $* |
| Apr-16-2025 | 217.61 $* | 221.84 $* |
| Mar-16-2025 | 267.5 $* | 272.79 $* |
| Feb-16-2025 | 265.36 $* | 270.7 $* |
| Jan-16-2025 | 263.99 $* | 268.67 $* |
Характеристики
SUNKKO 797DH Multi battery Function High Power Spot Welder Multi Pulse Spot Welding Machine 220V
Product Description
797DH battery spot welder
Sunkko 797DH is designed for people working in battery spot welding business. It has a great improvement in LCD display and design compared with sunkko 709 series.
Welding Thickness: The huge power output enables 797DH to weld pure nickel easily which thickness is 0.2mm(nickel coated steel: 0.3mm), even when you are welding batteries with the mobile welding pen, the welding thickness can be also up to 0.2mm.
Ways to increase the power output: You can adjust the welding current, welding pulses or the cluster pulse knob to increase the power output if you are welding a thicker nickel sheet.
LCD Display: The welding current and pulse can be easily set. On the basis of sunkko 709 series LCD, we added an extra part to show the dynamic welding current and pulse number during the welding process in real time. The value at the lower left corner stands for the dynamic welding current, 0.1 equals to 100 amps. The value at the lower right corner is the dynamic pulse quantity.
Attention: This spot welder can be used to weld the nickel, nickel plated steel, nickel plated iron, iron and other alloys, but it can't be used to weld metal including copper and aluminum.
Specifications
| Voltage | 220V, 50Hz or 110V, 60Hz |
| Power | 3.8kw instantaneously |
| Max. welding current | 800A (adjustable) |
| Pluse quantity | 2 to 16P (adjustable) |
| Welding thickness | 0.05 to 2mm(nickel coated steel: 0.3mm) |
| Mobile welding Pen | |
| Length | ≤22.8" |
| Cable cross sectional area | 16 mm2 |
| Dimension of welding pins | 1.5 x 7 mm |
| Max. welding current | 800A |
| Welding thickness | 0.05 to 2mm(both pure nickel and nickel coated steel) |
| Net Weight | 7kg |
| Machine dimension | 14x25x20cm |
Detailed Images
table size 58*84*14CM: 15KG
Packaging list
The standard welding pen is 70B model, if you need other types of welding pen, please contact us!
