WR-D20 1P 385V 20kA сглаживатель перепадов напряжения свяжитесь с нами для защиты от
- Категория: Power Strips >>>
- Поставщик: Zhejiang,Wrdz,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 1.6 $* | 1.68 $* |
| Jul-16-2025 | 1.65 $* | 1.11 $* |
| Jun-16-2025 | 1.70 $* | 1.72 $* |
| May-16-2025 | 1.33 $* | 1.18 $* |
| Apr-16-2025 | 1.10 $* | 1.77 $* |
| Mar-16-2025 | 1.6 $* | 1.89 $* |
| Feb-16-2025 | 1.30 $* | 1.53 $* |
| Jan-16-2025 | 1.97 $* | 1.64 $* |
Характеристики
Related Products
Product Description
Detailed Images
Rated Voltage(max. continous voltage) | Uc | 275V | ||||
Nominal discharge current(8/20μs) | In | 10kA | ||||
Max. discharge current(8/20μs) | Imax | 20kA | ||||
voltage protection level | Up | ≤1.2kV | ||||
Response time | tA | ≤25ns(L-N) | ||||
Max.Back up fuse | 125AgL/gG | |||||
Operating Temperature range | Tu | -40~80℃ | ||||
Cross-sectional area | 1.5mm²~25mm² solid/35mm²flexible | |||||
Mounting on | 35 DIN rail | |||||
Enclosure material | Purple module & light gray,UL94-V0 | |||||
Dimension | 4mods | |||||
Type of remote signaling capacity | Switching contact | |||||
Switching Capacity | AC:250V/0.5A; DC:250V/0.1A; 125V/0.2A; 75V/0.5A | |||||
Cross sectional area for temote signaling contact | Max.1.5mm² solid/flexible | |||||
Test standards | YD/T 1235.1; GB 18802.1; IEC 61643-1 | |||||
Certification | CE TUV CQC RoHS | |||||
