Ширина 47 мм SGR20N прямоугольный оксид антикоррозийный алюминий двойная ось Встроенная линейная

Rail mechanical properties:
Section shrinkage 40%
Yield strength ≥355Mpa
Tensile strength 600Mpa
Elongation 16%
Impact work 39J
Hardened hardness layer depth 0.8-2.5mm
Surface roughness Ra0.03-0.06
Chrome plating thickness 0.015-0.02mm
Hardness HRC60-64
Accuracy grade g6
Straightness ≤0.10/1000mm
Ovality <5μm (Rmax)
Material 45# steel/bearing steel

Aluminum body is made of international standard 6061 aluminum alloy. After processing, the whole black plating surface is treated specially. Acid and alkali resistant

Round bar mandrel imported from Taiwan for high frequency heat treatment chrome plated mandrel hardness HRC62±2 chrome plated surface to ensure no rust

Slider body sliding unit adopts CNC precision machining steel wheel to reduce rolling friction Smooth contact surface running low noise

Double-axis type series products are light-weighted, easy to install, easy to maintain, interchangeable, and suitable for
installation in any automated machinery and equipment

Professional Autonomous Production High-Speed Delivery Rapid Compared with other similar linear slide products


Application

Grinding machine, milling machines, lathes, drilling machine, and comprehensive processing machines, discharge manufacturing machine, boring machine, line cutting machine, precise measurement instrument, woodworking machinery, handling machine, and the shipping device


Product Description of Linear Guide Rail

Linear guides and rails provide a smooth, precision, guiding surface on which the rolling element of a linear bearing rides. They are an integral part of linear bearings, typically ordered separately from the rolling element component. They must exhibit this in terms of speed, temperature stability, accuracy and noise levels. Our linear guide available in several sizes to accommodate loads of all types, from light to heavy, and offer suitable for use in numerous applications, such as machine design requiring incorporation of linear guide products into the machine structure. We produce a complete range of linear guide designed to satisfy the most demanding requirements.

Linear bearings are used in automated machinery are more like the German imports of machine tools, paper bowl machine, laser welding machine and so on, of course, linear bearings and linear axes are used for matching. Like the linear guide is mainly used in high precision mechanical structure.

Slider - the movement from the curve into a straight line. The new rail system so that the machine get faster feed rate, spindle speed in the same circumstances, the rapid feed is linear guide features. Linear guide rail with the same plane, there are two basic components; a fixed component as a guide for other mobile devices. As the linear guide is a standard part of the machine tool manufacturer is. The only thing is processing a flat mounting rails and calibrated in parallel rails. Of course, in order to ensure the accuracy of machine tools, bed or column a small amount of scraping is essential, in most cases, installation is relatively simple.


Advantages of Linear Guideway
(1) the positioning precision is high
(2) less abrasion can long time maintain precision

(3) high speed movement and greatly reduced the power needed for drive
(4) can also withstand the loadfrom up and down or other directions
(5) easy assembling and a replacement

(6) the lubrication simple structure
