Гидравлический шланговый обжимной станок YONG FENG Y120
US $1950-$4100
Прямая Заводская поставка Высокоэффективная машина для
- Категория: Оборудование для производства резиновых изделий >>>
- Поставщик: Henan,Vipoo,Rubber,Products,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.69 $* | 0.32 $* |
| Aug-16-2025 | 0.94 $* | 0.97 $* |
| Jul-16-2025 | 0.12 $* | 0.23 $* |
| Jun-16-2025 | 0.96 $* | 0.61 $* |
| May-16-2025 | 0.66 $* | 0.99 $* |
| Apr-16-2025 | 0.36 $* | 0.68 $* |
| Mar-16-2025 | 0.43 $* | 0.78 $* |
| Feb-16-2025 | 0.58 $* | 0.74 $* |
| Jan-16-2025 | 0.9 $* | 0.93 $* |
Характеристики
Place of Origin | CN；HENAN |
Model Number | machine |
Brand Name | VIPOORUBBER |
Product Name | Hydraulic hose peeling machine |
Scope of locking (holding) | 6mm-51mm |
Bearing spindle | 10set |
Matching tool rod | 1pcs |
rated oil pressure | 2.5MPa |
Motor Power | 1.5kw-0.75KW（220V-380V） |
Overall dimensions | 625*480*1000mm |
weight | 65kg |
Hose cutting machine (peeling machine), an indispensable weapon for cutting high-pressure tubing hydraulic hoses. This product is widely used in automotive, engineering machinery, home appliances, welding and cutting equipment industries. This product is of high quality. It integrates the function of cutting and peeling rubber hoses. It can be used with a pipe press (beer pipe machine) to cut high-pressure oil pipes wound with steel wires. Features.
Mainly for hydraulic oil pipes of 6mm--51mm. Steel braided hose. Wrapped hose, one to six layers can be used.
Product use: Strip the outer rubber layer of high-pressure steel wire braided hose and high-pressure steel wire wound hose.
Instructions for use
Before turning on the machine, first install the corresponding peeling mandrel into the shaft sleeve, and tighten the top wire, then install the turning tool on the peeling tool bar, and adjust the length of the turning tool handle until it can be adjusted to cut the rubber. Length, then tighten the top wire of the fixed tool bar, and then check whether the fasteners are fastened again. After confirming, you can turn on the machine, and then you can test the hose. If the peeling is not too clean, you can continue to The shank of the turning tool is adjusted to the center so that a greater depth can be turned. If it is a hose wound with steel wire, turn on the switch depending on the winding direction, and the turning direction of the turning tool is determined by the reverse switch.
Working principle and working process
Insert the hose into the mandrel and gradually push the hose in, but the mandrel does not rotate.At the same time, the tool bar is driven by the motor, and the turning tool is firmly installed on the tool bar. , The outer layer of rubber was cut off by a turning tool, and the turning is completed, and the rubber tube can be pulled out.
Before turning on the machine, first install the corresponding peeling mandrel into the shaft sleeve, and tighten the top wire, then install the turning tool on the peeling tool bar, and adjust the length of the turning tool handle until it can be adjusted to cut the rubber. Length, then tighten the top wire of the fixed tool bar, and then check whether the fasteners are fastened again. After confirming, you can turn on the machine, and then you can test the hose. If the peeling is not too clean, you can continue to The shank of the turning tool is adjusted to the center so that a greater depth can be turned. If it is a hose wound with steel wire, turn on the switch depending on the winding direction, and the turning direction of the turning tool is determined by the reverse switch.
Working principle and working process
Insert the hose into the mandrel and gradually push the hose in, but the mandrel does not rotate.At the same time, the tool bar is driven by the motor, and the turning tool is firmly installed on the tool bar. , The outer layer of rubber was cut off by a turning tool, and the turning is completed, and the rubber tube can be pulled out.
Multiple workstations work together to improve timeliness, achieve the best standards, and deliver the fastest.
Packaging is according to the international transport standards for packaging, if necessary,can be customized
Customizable logo
Customizable logo
After the production of the goods is completed, the goods will be delivered in order of the order
The completion time of the goods depends on the size of the order quantity: 5-30 working days
The completion time of the goods depends on the size of the order quantity: 5-30 working days
Henan vipoorubber co., LTD., has 30 years of experience in production and sales
Main production and manufacturing rubber hose (tube flange dredging, sediment delivery hose (water), absorption), sand blasting hose, concrete pump pipe, oxygen acetylene hose, chemical resistant hose, PVC hose, fuel hose, hydraulic hose, steel wire braided hose,Industrial hose ,steel wire winding), high-pressure hose, peristaltic pump hose, garden hose expansion, hose connectors and other products, we are industry and trade integration company, has its own factory, a professional research and development technical team and efficient staff conscientiously.
\t\t\t\t\t\t\t\t\tFAQ \t\t\t\t\t\t\t
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white wearable woven bags. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 20 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
