automatic wall mortar cement spraying plastering putty machine
US $800.00-$2000
Хорошее качество поршневой шламовый раствор затирки насос/раствор спрей червячный насос/цементная штукатурка
- Категория: Mortar Spray Machines >>>
- Поставщик: Xingtai,Mingge,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.91 $* | 0.90 $* |
| Aug-15-2025 | 0.95 $* | 0.51 $* |
| Jul-15-2025 | 0.11 $* | 0.22 $* |
| Jun-15-2025 | 0.3 $* | 0.45 $* |
| May-15-2025 | 0.15 $* | 0.20 $* |
| Apr-15-2025 | 0.68 $* | 0.8 $* |
| Mar-15-2025 | 0.96 $* | 0.65 $* |
| Feb-15-2025 | 0.94 $* | 0.15 $* |
| Jan-15-2025 | 0.7 $* | 0.37 $* |
Характеристики
Product Description
Good quality Piston Slurry Mortar Grouting Pump / mortar spray worm pump/cement plaster spray machine
Modle | HLP-3 | HLP-3C | HLP-2 | 311 | 511 | 711 | Single cylinder plunger | Double cylinder plunger |
Power | 7.5KW | horsepower | 7.5KW | 4KW | 7.5KW | 7.5kw | 9kw | 9/11kw |
Voltage | 380V | Diesel | 380V | 220V/380V | 380V | 380V | 380V | 380V |
Input pressure | 8Mpa | 6Mpa | 6Mpa | 3-6Mpa | 5-8Mpa | 7-8Mpa | 6Mpa | 6Mpa |
Transmission of horizontal distance | 60m | 60m | 60m | 60m | 50m | 100m | ||
capacity | 5m³ | 3m³ | 3m³ | 2m³ | 3-5m³ | 6m³ | 5m³ | 7m³ |
Through the particles | <10mm | <10mm | <10mm | <4mm | <5mm | <7mm | <6mm | <6mm |
The vertical distance transport | 30m | 30m | 30m | 10m | 20m | 30M | 40M | 50M |
Weight | 380KG | 300KG | 260KG | 150KG | 260KG | 360KG | 380KG | 420KG |
Spraying speed | 150M2/h | 240M2/h | ||||||
Size | 1600*450*800mm | 1700*550*900 | 2000*800*1050mm | 2000*800*1050mm |
Features of putty spraying machine：
2. In addition to the electrical control box can switch, but also equipped with remote control switch spraying.
3. Gun connection with the feeding tube can be rotated for easy operation.
4. High efficiency, good quality.
5. Easy structure, easy to handling on-site,and accessories is cheap ,easy to maintenance.
1. Single cylinder & single-acting, ball valve, quick clamp connection, operation and cleaning conveniently.
2. Adopt special design rubber parts to connect to the feeding and back port, easy to disassemble.
3. V belt and gear transmission, high efficiency, low failure rate.
4. The special design of the working valve chamber ensures the mortar flow easily, small resistance, no deposition.
5. The screen adopts rubber spring with cone bolt installation, convenient disassembly.
6. The mixing shaft in the hopper is directly linked to the piston rod, thus this shaft is synchronously moved with the said piston rod effectively prevent mortar precipitation.
7. Equipped with special mortar nozzle, making spraying operation more smoothly, continuously and reducing the rebound effectively.
2. Adopt special design rubber parts to connect to the feeding and back port, easy to disassemble.
3. V belt and gear transmission, high efficiency, low failure rate.
4. The special design of the working valve chamber ensures the mortar flow easily, small resistance, no deposition.
5. The screen adopts rubber spring with cone bolt installation, convenient disassembly.
6. The mixing shaft in the hopper is directly linked to the piston rod, thus this shaft is synchronously moved with the said piston rod effectively prevent mortar precipitation.
7. Equipped with special mortar nozzle, making spraying operation more smoothly, continuously and reducing the rebound effectively.
Why Choose Us
High quality Various assorted categories; Factory direct; Timely after-sales service.
Welcome detailed customization. Appropriate price.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Our customers
Our Company
1:Packing in special plastic bags
2:Fixed in plastic bags to prevent it from falling off.
3:Seal with wooden box
2:Fixed in plastic bags to prevent it from falling off.
3:Seal with wooden box
FAQ
1.How long of the delivery time?
It takes about 15 working days to delivery the secondary structure column pump machine
2.what is the warranty time?
1 years
3.Do you have agent ?
We are looking for agent in every country, if you have interesting, feel free to contact us
4.How can we use the machine?
we will send the english user manual and video with the machine, if not enough, we can teach you online.
5.What is the MOQ:
1 set
6.What is the payment term?
30% deposit T/T , balance pay against copy of B/L if CIF or CFR.
50% deposit T/T, balanced pay off when we finish the production.
7.How long is the machine's life?
Our machine can use more than 30-50 years. Our old customer said it is very strong.
8. can we use alibaba trade assurance?
yes, welcome to use alibaba trade assurance.
9. Do you have any discount?
Yes, we have discount , specially for firm order or Alibaba Trade Assurance order.
10.How about the market ?
It is very popular in the market.
11.How can we go to your factory?
You can fly from your country to Beijing international airport by air, then you can take fast train from beijing to our city, it takes about 3 hours. we can pick you up from the railway station.
12.How can you delivery machine to us?
we can send machine to you by ship, by air and by express. as your like, i will help you to choose the best way.
13. Could you send more details of this machine to us?
Yes, we can send secondary construction column pump machine
catalogue, testing video, install video, more pictures and the user manual to you by email.
It takes about 15 working days to delivery the secondary structure column pump machine
2.what is the warranty time?
1 years
3.Do you have agent ?
We are looking for agent in every country, if you have interesting, feel free to contact us
4.How can we use the machine?
we will send the english user manual and video with the machine, if not enough, we can teach you online.
5.What is the MOQ:
1 set
6.What is the payment term?
30% deposit T/T , balance pay against copy of B/L if CIF or CFR.
50% deposit T/T, balanced pay off when we finish the production.
7.How long is the machine's life?
Our machine can use more than 30-50 years. Our old customer said it is very strong.
8. can we use alibaba trade assurance?
yes, welcome to use alibaba trade assurance.
9. Do you have any discount?
Yes, we have discount , specially for firm order or Alibaba Trade Assurance order.
10.How about the market ?
It is very popular in the market.
11.How can we go to your factory?
You can fly from your country to Beijing international airport by air, then you can take fast train from beijing to our city, it takes about 3 hours. we can pick you up from the railway station.
12.How can you delivery machine to us?
we can send machine to you by ship, by air and by express. as your like, i will help you to choose the best way.
13. Could you send more details of this machine to us?
Yes, we can send secondary construction column pump machine
catalogue, testing video, install video, more pictures and the user manual to you by email.
